- Page 1 PBP4VQ247FN ACH6420FR INSTRUCTION MANUAL CERAMIC HOB IO-HOB-0662 / 8071973 (02.2018 / v1)
-
Page 2: Basic Information
DEAR CUSTOMER, Your hob combines exceptional ease of use with excellent effectiveness. Once you have read the instructions, operating your hob will not be a problem. Before being packed and leaving the factory, the safety and functions of this hob were ca- refully tested. -
Page 3: Table Of Contents
TABLE OF CONTENTS Basic information ....................2 Safety instructions ....................4 Saving energy .......................8 Description of the appliance ................9 Installation......................11 Operation ......................14 Cleaning and routine maintenance ..............19 Emergency procedure..................21 Technical data .....................22... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or... - Page 5 SAFETY INSTRUCTIONS Warning: If the surface is cracked, switch off the ap- pliance to avoid the possibillity of electric shock. The appliance is not intended to be operated by me- ans of an external timer or separate remote-control system. You should not use steam cleaning devices to clean the appliance.
- Page 6 SAFETY INSTRUCTIONS ● Before using the ceramic plate for the first time read the Operating Manual carefully as thus you can ensure safe operation and avoid damage to the plate. ● If the ceramic plate is operated near a radio, TV set or other emitting device, please check whether the touch panel works correctly.
- Page 7 SAFETY INSTRUCTIONS ● The heating surface of the ceramic plate is resistant to thermal shock. It is neither hot nor cold-sensitive. ● Avoid dropping objects on the plate. A point hit, for example a falling bottle with spices, may in unfavourable circumstances lead to cracks and splits appearing on your ceramic plate.
-
Page 8: Saving Energy
SAVING ENERGY UNPACKING Everybody who properly The appliance is protected from damage during transpor- uses energy not only saves money but also consciously tation by its packaging. After unpacking please dispose acts in aid of the natural of the packing materials in a environment. -
Page 9: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Description of hob Rear left cooking zone Ø 145mm Rear right cooking zone Ø 180mm Front left cooking zone Ø 210mm Front right cooking zone Ø 145mm Control Panel 1. On/Off/Select a cooking zone 2. Cooking zone displays 3. - Page 10 INSTALLATION Making the worktop recess • Worktop thickness should be 28 - 40 mm, while its width at least 600 mm. The worktop must be flat and level. Edge of the worktop near the wall must be sealed to prevent ingress of water or other liquids.
-
Page 11: Installation
INSTALLATION Note. When installing the hob in the kit- chen worktop, install a partition panel, as shown on the picture. If the hob is to be installed above a built-in oven, installa- tion of the partition panel is not required. If the hob was installed in the kitchen Installing hob in kitchen cabinet worktop. - Page 12 INSTALLATION Installing hob - bracket • Use four “A” brackets for 38 mm thick worktops. Fit the hob into worktop opening as shown on figure2 and 3. To properly secure hob in 28 mm thick worktop, use four 15x15x50 mm wooden blocks in addition to “A”...
- Page 13 NSTALLATION Electrical connection Warning: This appliance must be earthed. The appliance must be installed by a com- petent electrician using a double pole control unit of 32 ampere minimum capacity with 3 mm minimum contact separation at all poles. We recommend that the appliance is connec- ted by a qualified electrician who is member of the N.C.E.I.C.
-
Page 14: Operation
OPERATION Before using the appliance for the first time ● Thoroughly clean your ceramic hob first. The ceramic hob should be treated with the same care as a glass surface. ● Switch on the ventilation in the room or open a window, as the appliance could emit an unpleasant smell during first use. - Page 15 OPERATION Control Panel When you connect the appliance to power, Child Lock indicator (5) will be on. Touch and hold the Child Lock sensor (5) until the indicator is off. Now you can use the appliance. No objects should be placed on the sensors (this could cause an error). Touch sensors should be always kept clean.
- Page 16 OPERATION Set the heating power In order to set the heat setting, first select the desired cooking zone using the cooking zone selection sensor (1). Then, when the cooking zone display (2) shows “ ” start setting the desired heat setting using the (+)(4) or (-)(3) sensor field. Switch off selected cooking zone Selected cooking zone may be switched off in the following way: 1.
- Page 17 OPERATION Automatic warm-up function Each cooking zone is equipped with an auto- Cooking heat Fast cooking time matic warm-up function. When this is activat- setting (min) ed, then the given cooking zone is switched 1’11” on at full power for a time depending on the 2’44”...
- Page 18 OPERATION Residual heat indicator Heat energy that remains accumulated in the cooking zone after cooking is called the resid- ual heat. The appliance displays two different levels of residual heat. When a cooking zone temperature is above 65°C and the cooking zone or the appliance is switched off, the relevant cooking zone display will show the letter "H".
-
Page 19: Cleaning And Routine Maintenance
CLEANING AND ROUTINE MAINTENANCE Daily cleaning and proper maintenance have crucial impact on the durability of your ceramic plate. Clean the ceramic plate observing the same rules as for glass. Never use abrasive or aggressive clean- ing agents, scrubbing powders or scratching sponges. - Page 20 CLEANING AND ROUTINE MAINTENANCE Never apply cleaning agent on a hot hotplate. Caution! Leave the cleaning agent to dry and then If from any reason you are not wipe it off with a wet cloth. Any residuals of able to control the switched on cleaning agents should be wiped off with a plate, switch off the main switch damp cloth before heating the plate for the...
-
Page 21: Emergency Procedure
EMERGENCY PROCEDURE Every time when emergency situation occurs you should: ● switch off the working assemblies of the plate ● disconnect power supply ● call in the service ● as some minor faults can be removed by the user in accordance with the be low specified instructions, before calling the Customer Service please go thro ugh the Table checking every point. -
Page 22: Technical Data
TECHNICAL DATA Rated voltage: 230/400V 1N ~50Hz Rated power: 6,5 kW Model: PBP4VQ247FN ACH6420FR - hotplate: 2 x Ø 145 mm 1,2 kW - hotplate: 1 x Ø 180 mm 1,8 kW - hotplate: 1 x Ø 210 mm 2,3 kW... - Page 23 Product information given in accordance with Commission Regulation (EU) No 66/2014 supplementing Directive of the European Parliament and Council Directive 2009/125/EC with regard to eco -design requirements for household ovens, hobs and range hoods Household electric hobs ACH6420FR Model identifier PBP4VQ247FN 23527...
