Sanyo DC-MCR80M Instruction Manual page 7

Micro component system
Hide thumbs

Advertisement

Table of Contents
Use compact discs bearing the symbol shown. In addition to conven-
tional 12 cm CDs, this system can be used to play 8 cm CDs without
an adapter.
1. Press the i button to select "CD" function. "CD" appears on the
display, then "CD" is replaced by the CD mode display.
2. Press the q OPEN/CLOSE button to open CD compartment,
"OPEN" appears.
3. Place the disc with the label facing up on the disc turntable.
(Place only one disc at a time.)
4. Press the q OPEN/CLOSE button again to close CD compartment,
"CLOSE" display briefly, "READING" blinks for several seconds,
then the total number of tracks and total playing time on the disc
appear.
Note:
If a badly scratched disc is loaded or if the disc is loaded with the
label facing downward, "NO DISC" appears. If this occurs, load
the disc correctly or replace the damaged disc.
5. Press the i button. Play starts from the first track.
TRACK
The current track number and elapsed playing time are displayed.
6. Press the n button to end disc play.
When the last track has been played, the player stops
automatically.
Notes on handling compact discs
-
Do not expose the disc to direct sunlight, high humidity or high
temperatures for extended periods of time.
-
Discs should be returned to their cases after use.
-
Do not apply paper or write anything on the disc surface.
-
Handle the disc by its edge. Do not touch the playing surface
(glossy side).
-
Fingerprints and dust should be carefully wiped off the playing
surface of the disc with a soft cloth.
Wipe in a straight motion from the centre to the outside of the
disc.
-
Never use chemicals such as record cleaning sprays, antistatic
sprays or fluids, benzene or thinner to clean compact discs.
To start play from the desired track
Select the track by using the e or f button, then press the i
button.
Temporarily stopping play
Press the i button, elapsed playing time blinks on the display. To
resume play, press the button again.
CD PLAY
Skip play
To skip to track 6 while track 3 is playing, press the e button repeat-
edly until "6" appears (in the track section) on the display. To skip back
to track 3 while track 6 is playing, press the f button repeatedly until
"3" appears.
-
The number buttons on the remote control can also be used for
skip play. To skip to track 6 while one track is playing, press 0, then
6.
Search (forward/reverse)
If the e or f button is pressed during play, the player will search at
high speed in the forward or reverse direction while the button is being
pressed. When the button is released, normal play will continue.
Repeat play (Remote control only)
Press the PRESET+/REPEAT button repeatedly before or during play to
select various repeat mode available.
Each time the PRESET+/REPEAT button is pressed, the repeat mode
changes as shown below:
"REPEAT" blinks
(Repeat one track)
(Normal play mode)
Random play (Remote control only)
1. Press the PRESET-/RANDOM button, "RANDOM" appears.
2. Press the i button. All tracks on the disc are played in random
order.
3. To cancel random play, press the PRESET-/RANDOM button again,
"RANDOM" disappears.
-
Random play will not function during programmed play.
PROGRAMMED PLAY
Up to 32 tracks on a disc can be programmed for play in any order.
-
First, select "CD" function and load a disc that you want to programme.
-
The tracks must be programmed in the stop mode.
-
The same track can be programmed more than once.
1. Press the MEMORY button.
PROGRAM
2. Select a track by using the e or f button.
-
The number buttons on the remote control can also be used.
PROGRAM
3. Press the MEMORY button.
PROGRAM
4. Repeat steps 2 - 3 to programme additional tracks.
5. Press the i button to start programmed play.
PROGRAM
-6-
"REPEAT"
v
(Repeat all tracks)
Released
TRACK
TRACK
TRACK
TRACK
appears
