Tuner
Reception frequency:
FM: 87.5 - 108 MHz
AM: 522 - 1710 kHz (9 kHz step)
520 - 1710 kHz (10 kHz step)
CD player
Type:
2-channel stereo
Sampling frequency:
44.1 kHz
Pick-up:
Optical 3-beam semiconductor laser
Laser output:
0.6 mW (Continuous wave max.)
Wave length:
790 nm
Wow/flutter:
Below measurable limits

SPECIFICATIONS

General
Output power:
10 W x 2 (at 4 ohms, 10% distortion)
Outputs:
SPEAKERS: 4 ohms
PHONES: 8 - 32 ohms
Power requirements:
AC 230 - 240 V, 50 Hz
Power consumption:
30 W
Dimensions:
256(W) x 88(H) x 286(D) mm
Weight:
2.9 kg
Speaker systems
Type:
2 way bass reflex
Unit used:
Woofer: 8cm
Tweeter: 3.5cm
Maximum power-handling capacity:
20 W (peak)
Nominal impedance:
4 ohms
Dimensions:
115(W) x 233(H) x 192(D) mm
Weight:
1.9 kg (per speaker)
Specifications subject to change without notice.
