Manage Saved Screen Snapshots
Saved Screen Snapshots can be viewed from the Snapshot and Recording View. If Screen Snapshot Waypoint is turned on when the
screen snapshot is taken, you can view the saved file from the Chart View.
NOTE: A microSD card must be installed in the control head to use the Snapshot and Recording features.
Display a Saved Screen Snapshot from Snapshot and Recording View
1. Display the Screen Snapshot and Recording View on-screen.
2. Select a Snapshot: Press the UP or DOWN Cursor keys to scroll through the saved files.
3. Display: Press the RIGHT Cursor key.
4. Close: Press the LEFT Cursor key.
saved
screen
snapshot
(selected
file)
scroll bar
saved
recording
Screen Snapshots and Recordings
Screen Snapshot and Recording View
Scroll through the List
108
Display
selected file
summary
microSD
card storage
(yellow =
used space)
