Humminbird HELIX 5 G2 SERIES Operation Manual page 107

Take Screen Snapshots
Screen Snapshots are saved pictures of the view on the screen. The screen snapshot will include the menus, dialog boxes, warnings,
and messages that were active when the screen snapshot was taken. If Screen Snapshot Waypoint is turned on, a waypoint will also
be saved at the boat or cursor location when you take a screen snapshot.
NOTE: A microSD card must be installed in the control head to use the Snapshot and Recording features.
1. From any view or cursor location you want to capture, press and hold the MARK key.
Taking a Screen Snapshot
Press and Hold to
Take a Screen Snapshot
107 Screen Snapshots and Recordings
