U S E R ' S M A N U A L
CAUTION
•
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
•
This User's Manual includes detailed usage instructions for your product.
•
Please read this manual thoroughly.
•
Figures and illustrations in this User Manual are provided for reference only
and may differ from actual equipment appearance. Equipment design
and specifications may be changed without notice.
[
]
promultis
lightning II touchscreen
lightning II touchscreen
For more exciting multitouch products visit
www.promultis.info
or call +44 (0) 239 251 2794
Advertisement
Table of Contents
Related Manuals for PROMULTIS PM-TS43A/32
Summary of Contents for PROMULTIS PM-TS43A/32
- Page 1 Figures and illustrations in this User Manual are provided for reference only and may differ from actual equipment appearance. Equipment design and specifications may be changed without notice. For more exciting multitouch products visit promultis lightning II touchscreen www.promultis.info or call +44 (0) 239 251 2794...
- Page 2 Interactive Touch Screen INSTRUCTION MANUAL PM-TS43A/32 PM-TS55A/32 PM-TS65A/32 PM-TS65A4K/32 PM-TS75A/32 PM-TS84A4K/32 Before connecting, operating or adjusting this product, please read the manual completely. Please keep this manual for future reference.
-
Page 3: Table Of Contents
Contents Important Information Important Safety Precautions Important Notice Identification of Controls Remote Control Setting Up Connections Basic Operations Device Settings Network Settings Menu List Using USB Multi Media Player Troubleshooting Specifications... -
Page 4: Important Information
IMPORTANT INFORMATION If the screen is not positioned in a stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided by taking simple precautions such as: Use cabinets or stands recommended by the manufacturer of the screen Only use furniture that can safely support the screen... -
Page 5: Important Safety Precautions
Important Safety Precautions Electricity may cause personal injuries and property damage if improperly handled. The screen has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. - Page 6 Important Safety Precautions (Continued) 15. Stand---Use only with the trolley stand or wall mount specified by the manufacturer, or sold with the apparatus. Do not place the product on an unstable trolley stand or wall mount. Placing the product on an unstable base can cause the product to fall, resulting in possible serious injuries as well as damage to the product.
-
Page 7: Important Notice
Important Notice About Location/ Do not use in hot and cold rooms (locations) Environment When the unit is used in rooms (locations) with low temperature, the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal. -
Page 8: Identification Of Controls
Identification of Controls :Switch the screen power on or standby. : Press the button to display input source menu or exit the menu screen. : Press the button to return to previous menu. : Press the button to display desktop (Home page) on the screen. -
Page 9: Remote Control
Remote Control Switch the screen power on or Standby Switch to AV mode Switch to VGA mode Switch to TV mode Switch to HDMI mode Note: If no RF, this button has no function. Display or exit the current Select picture mode program information Select aspect ratio Select sound mode... -
Page 10: Setting Up
Setting Up Installing remote control Batteries To install remote control batteries: Open the battery cover. Insert two AAA batteries into the battery compartment. Make sure that the + and – symbols on the batteries match the + and – symbols in the battery compartment. -
Page 11: Connections
Connections Cautions Before Connecting When connecting an external device to the screen, make sure that the screen and the device are turned off. Check the plugs at the ends of cables to make sure that they are the correct type before you try plugging them into jacks on the screen. - Page 12 Connections VGA cable Monitor VGA cable VGA 1 Audio cable VGA cable PC, etc. Audio cable VGA devices VGA 2 USB cable USB devices HDMI 1 HDMI cable (MHL) HDMI devices HDMI cable HDMI 2 (ARC) DP cable DP devices DP IN USB 2.0 Tighten the WiFi antenna in clockwise direction.
-
Page 13: Basic Operations
Basic Operations Turning the screen on or off Plug the power cord into an AC Power outlet. Press Power Switch on the screen. Now the screen is in standby mode. Wait a moment until the power indicator lights up, then press POWER turn on the screen. - Page 14 Basic Operations(Continued) Home Menu Overview In all applications, press and drag the icon to on Home page for shortcut created, press and drag the Shortcuts you created on Home page shortcut to X for shortcut deleted. Show all applications Note: When using the app Camera, store the data onto your connected USB device.
-
Page 15: Device Settings
Device Settings Show all apps Display system Storage Network Setting Display information of the unit To set default input method To set Android keyboard(AOSP) To set on-screen language To set Date and time Note: To manually set date and time, you should toggle “Automatic Date &... -
Page 16: Network Settings
Network Settings Internal routing setting Reset Internal Router by hardware. Password is required for this operation Input the default UserName: and is the same password to admin, skip the default password access Lock menu. setting as there is no default password, then press Login button Ethernet setting Set the Built-in WiFi... - Page 17 Network Settings(Continued) Wired Network Setting Internal router Method 1: Easy Set Wizard Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Select Gateway Easy Set Wizard Next There are five methods to connect with network, choose your preferred one.
- Page 18 Network Settings(Continued) Wired Network Setting Internal router Method 2: Professor model Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Select Setup Wizard Professor Model Select Gateway Next Next Next...
- Page 19 Network Settings(Continued) Wireless Network Setting Internal router Method 1: Easy Set Wizard Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Wireless Select Repeater Mode Easy Set Wizard Next There are five methods to connect with network, choose your preferred one.
- Page 20 Network Settings(Continued) Wireless Network Setting Internal router Method 2: Professor model Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Professor Model Select Select Wireless Setup Repeater Next Wizard Mode...
- Page 21 Network Settings(Continued) Wireless Network Setting Built-in WiFi card Turn on/off the built-in WiFi Display of all the Wi-Fi signal. Select your desired Wi-Fi signal. Add new network. Scanning Wi-Fi direct device. Setting Portable WiFi hotspot. Turn on enable Mcast.
-
Page 22: Menu List
Menu List Adjusting Picture mode Picture Mode Select your favourite picture mode for each input [Standard] / [Soft] / [User] / [Game] / [Writing] / Dynamic]. Adjust the contrast. Contrast Brightness Adjust the brightness. Adjust the image hue. (Only for NTSC system) Sharpness Adjust the sharpness. - Page 23 Menu List Adjusting Setting menu Select On to automatically recognition source. Source Auto Switch Color Range Select color range. (Only for HDMI mode) Select HDMI EDID Ver. HDMI EDID Ver. MHL Auto Switch Select On to automatically switch to the MHL input when it connected.
-
Page 24: Using Usb Multi Media Player
Using USB Multi Media Player Using USB multi media player You can connect a USB storage device to your screen to view compatible photo, movie or play compatible music so that the sound can be output from the screen’s speaker. Home To use USB multi media player, please go to USB source by pressing USB button. - Page 25 Using USB Multi Media Player Playing Photo With the photo viewer, you can view compatible photos (in JPG, BMP or PNG format). Also you can zoom, rotate photo, etc. Previous photo Play/pause Show information Next photo Rotate clockwise Zoom in Rotate anti-clockwise Zoom out Note: You can also use...
- Page 26 Using USB Multi Media Player Playing Movie With the USB movie player, you can play compatible movie (in AVI, MPG, MPEG, DAT, MP4, TS, RM/RMVB, or MKV/MOV format). Previous movie Now AB repeat starts. To cancel, Adjust the volume Fast reverse highlight Section replay and AB Section repeat Play/pause...
-
Page 27: Troubleshooting
Troubleshooting If, after reading these operating instructions, you have additional questions related to the use of your screen, please call the services center in your local area. Before calling service, please check the symptoms and follow suggested solutions. Remote Control Problem Possible Solutions The batteries could be weak. -
Page 28: Specifications
Specifications Model No. PM-TS43A/32 PM-TS55A/32 PM-TS65A/32 PM-TS65A4K/32 PM-TS75A/32 PM-TS84A4K/32 AC 100-240 V, 50 / 60 Hz Power Source Current Max. 1.2 A 2.4 A 2.8 A 2.8 A 5.2 A 6.2 A Standby condition* < 0.5 W < 0.5 W <... - Page 29 PRINTED ON RECYCLED PAPER 5944041960...
