Accessory support

Mitel M695 Programmable Key Module (PKM)

Up to three Mitel M695 PKMs can be attached to the right of the Mitel MiVoice 6940 IP phone
providing you with 84 additional programmable keys (28 keys per PKM).
The Mitel M695 PKM features a 4.3" 480x272 pixel color backlit LCD display that provides a unified
graphical user experience with the Mitel MiVoice 6940 IP phone.
The Mitel M695 PKM supports the same programmable key functions as the Mitel MiVoice 6940 IP
phone. The programmable keys can only be programmed by your System Administrator.
Notes:
1. For the Mitel MiVoice 6940 IP phone, the USB port on the phone will be disabled (
phone is being powered using 802.3af PoE and two or more expansion modules are
connected. Use a Mitel approved power adapter or power the Mitel MiVoice 6940 IP phone
using 802.3at PoE plus to ensure the USB port will be functional when two or more expansion
modules are connected.
2. For information how to install your Mitel M695 PKM, see the Mitel M695 PKM Installation Guide.
Accessory support
) if the
91
