Technical specifications

Originals
Transmission and reflection originals in positive or negative, color, gray
scale or line art, with or without existing screen.
Scanning technology
CCD flatbed with zoom lens.
Scanning area
Transparencies: 210 x 420 mm (8.3" x 17").
Reflectives:
Speed
Single-pass scanning.
ScanMate F6: up to 300,000 pixels per second.
ScanMate F8 Plus: up to 600,000 pixels per second.
Scan resolution
ScanMate F6: optical up to 3000 dpi, interpolated up to 9000 dpi.
ScanMate F8 Plus: optical up to 4000 dpi, interpolated up to 11,000 dpi.
Optical density
Range: 3.7, max:: 4.0.
Sensor unit
Trilinear CCD element, 8000 pixels wide.
Color resolution
3 x 16 bits
Focus
Automatic or user-adjustable via software.
Light source
Fluorescent lamp.
297 x 420 mm (11.7" x 17").
ScanMate F6 / ScanMate F8 Plus • Operator's Manual

SPECIFICATIONS

1•1
