Installation
2 • Turn off all the equipment.
3 • Set the scanner to the desired SCSI address.
• When the scanner leaves the factory, the SCSI ID is set at
2. If you want to change it, please use only the addresses
from 1-6. Address number 7 is for setting the CCD
platform and lens platform in the transportation
position. Addresses 0, 8 and 9 are for service purposes
only and should not be used.
• To change the address, press the push switch above or
below the SCSI address window on the back of the
scanner until the desired number appears in the window.
On/off
switch
4 • Use the supplied SCSI cable to connect the scanner to one of the other SCSI
units, so that all the units form a chain with the computer at one end.
5 • Place the terminator in the free SCSI socket of the last unit in the chain.
2•4
ScanMate F6 / ScanMate F8 Plus • Operator's Manual
Fuse holder
Power socket
2
2
SCSI address selector.
Push the small button above
or below the window to
change the address.
SCSI sockets
