1.4 LED Indicator

The Mercury On-The-Go Pro has a blue LED at the front. The LED emits a solid blue light when the unit is powered
on and flashes during drive activity.

1.5 Rear View

1

1.5.1 Rear Features

1. USB 3.1 Gen 1 port — Attach the included USB 3.1 Gen 1 (Standard-A to Micro-B) cable here.
2. On/Off switch — Power the Mercury On-The-Go Pro on and off here.
3. Power input — Connect the optional 5V power adapter here (sold separately).
4. FireWire 800 ports — Attach the included 9-9 pin FireWire 800 cable to one of these ports and to the computer.
Use the other FireWire 800 port to daisy-chain other FireWire 800 devices. NOTE: Any device daisy-chained to the
Mercury On-The-Go Pro must be powered by its own power supply. The Mercury On-The-Go Pro cannot bus power
other devices.
OWC MERCURY ON-THE-GO PRO
1 2 3
4 3 2
3
