Introduction

The Venue Wideband receiver is a modular rack mount
design for use with a wide variety of transmitters from
Lectrosonics and other manufacturers. Designed for
maximum versatility and performance, the wideband
design offers the flexibility needed in today's changing
and increasingly congested RF environments.
A Venue receiver is a "system" that consists of a master
unit and up to six receiver modules. Two different types
of receiver modules are available. The standard module
(VRS) is an excellent choice for fixed installations where
fairly clear RF spectrum is available. The tracking mod-
ule (VRT) is a more costly alternative, but its tracking
front-end makes it the better choice for use in congest-
ed RF environments. VRpanel software is included to
simplify setup and monitoring.
This guide covers the essential steps and settings
needed to get a Venue system up and running. It covers
the hardware installation, configuration using the LCD
on the master unit, setting up a USB port on the com-
puter and installing the VRpanel software.
LecNet2 software runs under Microsoft Windows
Vista and Windows 7 operating systems.* An online
TM
Help in the software includes a listing of commands
used to control the Venue through the serial ports.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. The equip-
ment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio com-
munications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television recep-
tion, which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that which the receiv-
er is connected
• Consult the dealer or an experienced radio/TV technician for help
Changes or modifications to this equipment not expressly approved by Lectrosonics, Inc.
could void the user's authority to operate it.
Rio Rancho, NM, USA
Digital Hybrid Wireless™ Modular Receiver System
XP,
®
* Windows is a registered trademark of Microsoft Corp.
Vista is a trademark of Microsoft Corp.
3
