Summary of Contents for Laney Cub 212R
- Page 2 At the same time we believe we have not lost sight of the reason Laney was founded in the first place - a dedication to building great sounding amplification for working musicians.
- Page 3 DARK ART tone. We hope you get a kick out of using your CUB-212R, we certainly did designing and making it. Best wishes from all at Laney...
-
Page 4: Important Safety Instructions
Important Safety Instructions WARNING: When using electrical products, basic cautions should always be followed, including the following: 1. Read these instructions. 2. Keep these instructions safe. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. - Page 5 Your Laney amplifier has undergone a thorough two stage, pre-delivery inspection, involving actual play testing. When you first receive your Laney amplifier, follow these simple procedures: If you should wish to change the factory fitted (i) Ensure that the amplifier is the correct voltage for the country it is to be plug yourself, ensure that the wiring convention used in.
-
Page 6: Front Panel Controls
Front Panel Controls POWER SWITCH: Main power switch for the unit. Tube amplifiers take between 30 seconds and 2 minutes to warm up and be ready to play after switching on, this is normal. POWER INDICATOR: This lamp will be lit when the amplifier is switched on. REVERB: Controls how much reverb is added to your sound. -
Page 7: Rear Panel Controls
EXTENSION CABINET: Use to connect an 8-16 ohm extension cabinet. Please note mismatched impedance will reduce the amplifiers performance and in some cases may cause damage to your amplifier. Try your CUB12R into a Laney extension cabinet - you will be amazed. -
Page 8: Sample System
LZB1 2 3 4 www.laney.co.uk IRT412 Input Link Power Rating 320W Serial Number: LZB1 2 3 4 16 Ohms Designed in the UK by Laney Made in China ...or with the neighbours!! (To avoid poor sound only use good quality guitar cables). -
Page 9: Specifications
Specifications Nominal Supply Voltage ~100V, ~115V, ~220V, ~230V, 50/60Hz Operating voltage Factory set Mains fuse Rating ~100-~120V T500mA L 250V, ~220-240V T250mA L 250V Power Consumption Output Power Rating Loudspeaker 2 x 12" Custom Drivers 8 Ohm Loudspeaker outputs Extension speaker socket (Disconnects Internal speakers) (8 - 16 Ohm Impedance) Features Class A/B Push/Pull circuitry... - Page 10 Typical output tube problems can be; sound lacking in punch, sound lacks extreme highs or lows and low level hum. Exact replacements for the preamp tube and output tube are available from Laney via your dealer.
- Page 11 It must be taken to an approved recycling centre according to the recommendations of the WEEE (Waste Electrical and Electronic Equipment) directive applicable in your country. In the interest of continued development, Laney reserves the right to amend product specification without prior notification.
- Page 12 Model number: Serial number: Place of purchase: Date of purchase: Please complete for future reference.
