9
Turn the lever as far as it will go
counterclockwise.
10
Push down the lever.
11
Close the front cover.
CAUTION
– Be careful not to get your fingers caught.
– If you cannot close the front cover, do not force it to
close. Open the front cover and pull out the toner
cartridge, then reinsert the cartridge into the machine.
49

Drum Unit

When <REPLACE THE DRUM> appears on the
LCD display, replace the drum unit.
Do not throw used drum unit into open flames, as they may
ignite the toner remaining inside the unit, and result in burns or
a fire.
If you use the machine without inserting the drum unit
A
<INSERT THE DRUM> appears on the LCD display. In this
case, turn OFF the main power, and install the drum unit into
the machine.
1
2
WARNING
CAUTION
Open the left cover.
Holding the grips on the drum unit, slightly
lower and remove it from the machine.
CAUTION
Do not touch the fixing assembly as it becomes very hot
during use.
