Summary of Contents for Goodmans XB25CDG

  • Page 2 I M P O R T A N T S A F E G U A R D S WARNING : To prevent fire or shock hazard do not expose this unit to rain or moisture. CAUTION : DANGEROUS VOLTAGES EXIST INSIDE THIS UNIT, DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL, DISCONNECT FROM MAINS SUPPLY WHEN NOT IN USE.
  • Page 3 M A I N T E N A N C E A N D C A R E SOME DO\S AND DON\TS ON THE SAFE USE OF EQUIPMENT This equipment has been designed and manufactured to meet European safety standards but like any electrical equipment, care must be taken if you are to obtain the best results and safety is to be assured.

  • Page 4: Table Of Contents

    T A B L E O F C O N T E N T S Location of controls ........................ 4 Introduction ..........................5 Installation ..........................5 Audio In and Aux Out ......................5 Sound Control .......................... 6 Headphones ..........................6 Using the microphone ......................

  • Page 5: Location Of Controls

    L O C A T I O N O F C O N T R O L S FRONT PANEL 21. MIC 2 Volume Control 1. Power Button 22. MIC 1 Volume Control 2. DBBS Indicator 23. MIC 2 Input Socket 3.

  • Page 6: Introduction

    INTRODUCTION The XB 21/25 operates on a power supply of 230V 50Hz AC. The XB 21/25 contains the following facilities. • Digital audio CD and Graphic player. • A twin cassette player with high speed dubbing, one touch record and sequential playback capability.

  • Page 7: Sound Control

    AUXILIARY AUDIO OUT There is a pair of RCA sockets at the rear of the unit marked AUDIO OUT L/R. This allows the audio signal generated by the XB21/25 to be connected to a separate audio amplifier for further amplification. Output level 1 volt max. S O U N D C O N T R O L MUTE •...
  • Page 8 SINGING TO MUSIC The microphone can operate together with the TAPE, AUX, CD functions. • Select the desired function and operate that function according to the instructions given. • Insert the supplied microphone into either MIC input socket. • Move the microphone ON/OFF switch to the ON position and operate the microphone according to the instructions given in the PA section.

  • Page 9: Loading Discs

    L O A D I N G D I S C S LOADING AND UNLOADING CD OR CD+G • Set the FUNCTION Selector to the CD position. • Press the CD Open/Close Button to open the disc compartment. • Once the CD door has opened, remove a disc from its case and place it carefully in one of the indentations in the compartment with the label side facing up.

  • Page 10: Connecting To The Tv

    CONNECTING TO THE TV Connect scart lead to TV and XB21/25 Connect one end of the supplied scart cable to your TV and and select AV on your TV. the other end to the scart jack at the rear of the XB21/25. Make sure you select AV channel on your TV.

  • Page 11: Disc Skip

    Repeatedly pressing the Skip Down Button makes the CD player skip back through the disc track by track. Once the beginning of the first track is reached, the CD player will not go back any further. Notes: The Skip Up/Down Buttons can be used to select a desired track to play from before disc play starts.

  • Page 12: Listening To Tape

    Any track can be programmed to play more that once. If you press the Stop Button during PROGRAM mode, the entire program will be erased from memory. LISTENING TO PROGRAMMED TRACKS Program your selection of tracks by following the procedure shown earlier. Press the Play/Pause Button.

  • Page 13: Recording

    • Adjust the Volume Control to the appropriate level. • When Tape B reaches the end and stops, Tape A starts playing back automatically. • When Tape A reaches the end, it will automatically stop. RECORDING RECORDING FROM CD • Select the CD FUNCTION , and insert your disc.

  • Page 14: Cassette Care

    C A S S E T T E C A R E Two common causes of trouble experienced when using cassettes are:-- Tape jamming -- Leading to uneven speed in playback, and Tape tangling -- Where the tape itself around vital parts of the mechanism. To reduce the likelihood of these problems occurring, the following precautions should be observed.

  • Page 15: Maintenance And Care

    M A I N T E N A N C E A N D C A R E Electronic products of this kind should never be subjected to extreme temperatures or high humidity. For instance, this set should not be placed in bathing areas or around stoves and radiators.

  • Page 16: Important Notes

    I M P O R T A N T N O T E S Hearing is very important to you and to us so please take care when operating this equipment. It is strongly recommended that you follow the listed guidelines in order to prevent possible damage or loss of hearing.

  • Page 17: Trouble Shooting

    T R O U B L E S H O O T I N G SYMPTOM REMEDY TAPE 1. No Audio from tape. Tape function has not been selected, Volume has not been set. 2. Poor Voice sound from tape. Tape heads are dirty, clean heads with a proprietary tape head cleaner.

  • Page 18: Specifications

    S P E C I F I C A T I O N S Power Supply : 230V ~ 50Hz CD Section System Frequency response : 20Hz ~ 20KHz (+/- 3dB) S/N ratio : 65dB Wow and Flutter : immeasurable D/A converter : 1 bit DAC with 8 times oversampling digital filter Number of Program...
