KARAOKE MACHINE
LINE IN
PAIRING
MODEL:339562
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 339562 and is the answer not in the manual?

Questions and answers

Related Manuals for Goodmans 339562

Summary of Contents for Goodmans 339562

  • Page 1 KARAOKE MACHINE LINE IN PAIRING MODEL:339562 USER MANUAL...
  • Page 2 Welcome Your Karaoke Machine In The Box Mains Power Front View Indicator 2.5 Rear View 2.6 Top View Quick Setup Connecting Your Karaoke Machine to a TV Display Lyrics on a TV Screen TV Connection for Audio & Video TV Connection with SCART Adapter 3.5 Audio Connection to an External Amplifier 3.6 Connecting the Microphone(s) Fitting the Microphone Holders...
  • Page 3 4.10 Echo Effect (Microphone Only) 4.11 Balance Control 4.12 A.V.C Control (Auto Voice Control) 4.13 LED Light & Water Display 4.14 Bluetooth Audio Troubleshooting Technical Specifications Customer Support...

  • Page 4: Mains Power

    Welcome Thank you for choosing this Goodmans product. We have been making electrical products for the British people for over 90 years. Each of our products have been carefully designed to be great at what they do and this one is no exception. We hope you enjoy your new Karaoke machine.

  • Page 5: Front View

    2.3 Front View Water Effect Power ON/OFF Button Press to switch between. Power ON and standby mode. Master Volume Adjusts the volume level of the speaker. Microphone Holder Balance Button Adjust the left & right audio balance. USB Port Connect a USB flash drive for MP3 playback.
  • Page 6 Play/Pause Button AVC Switch Controls the music volume level when singing. MIC Input +10 Button The number of the track is increased by ten. ECHO Control MIC Volume Button Mode Button Press mode to switch between CD/Bluetooth/ USD mode. Indicators LINE IN PAIRING...
  • Page 7 2.4 Indicator CDG Indicator Indicates when a CD+G track is being played. Play/Pause Indicator Indicates when in play or pause mode. Prog Indicator Indicates when the program function is active. Repeat Indicator Indicates when the repeat mode is active. 2.5 Rear View Composite Video Output Connect to a TV video input.

  • Page 8: Quick Setup

    Quick Setup 3.1 Connecting Your Karaoke Machine to a TV An audio/video (AV) cable is supplied to give you the option of connecting the unit to an external amplifier and/ or a TV to display lyrics on-screen. The cable has three RCA jacks at each end. White and Red are for left and right audio connections and the Yellow is for connecting the video.
  • Page 9 Select the appropriate video channel on your TV to view the lyrics on-screen and hear the sound from the TV speakers. AUDIO IN VIDEO IN 3.4 TV Connection with SCART Adapter If your TV does not have the same red, white & yellow input sockets, you can use a RCA to SCART adapter (not supplied).

  • Page 10: Connecting The Microphone(S)

    3.5 Audio Connection to an External Amplifier As an alternative to listening to the audio through your TV or internal speakers, you can listen through your home stereo system. Connect the RED & WHITE jacks of the supplied AV cable to the 'AUDIO OUT' sockets on the rear of the karaoke machine.

  • Page 11: Connecting The Power

    3.7 Fitting the Microphone Holders Two microphone holders are supplied to store the microphones when not in use. Locate the left MIC holder and insert into the recess marked 'L' until you hear a click and the holder is secure. Repeat the process for the right holder.

  • Page 12: Adjusting The Volume

    Power ON/OFF & Auto Standby Press the POWER ON/OFF button to wake from Standby mode. Press the POWER ON/OFF button again to enter Standby mode. Due to new ECO regulation requirements this product incorporates a power saving feature. Once audio playback has ceased and the unit has stood idle for approximately 15 mins, it will switch into standby mode.

  • Page 13: Operation

    Press PLAY on the audio device. Adjust the volume to your desired level. When connecting via the headphone output the volume of the karaoke machine is affected by the volume control on the player. Ensure that the audio source (such as an MP3 player) is set to about 70-80% to avoid distortion.

  • Page 14: Play A Song

    4.5 Load a USB Flash Drive Insert a USB flash drive into the USB port on the front of the karaoke machine. 4.6 Play a Song Follow the steps above to load a disc or USB flash drive (if not already loaded).

  • Page 15: Skip Tracks

    4.7 Skip Tracks Press the “ ” button once during playback to skip to the next track. To skip to a specific track, press this button several times until you reach the track number required. Press the “ ” button once during playback to return to the beginning of the current track.
  • Page 16 Repeat Single/All Track(s) During playback pressing the REPEAT button will flag the current track to repeat indefinitely. You will see the REPEAT indicator to the right of the display flash. Pressing the REPEAT button again will repeat all tracks on the disc. You will see the REPEAT indicator to the right of the display stop flashing and remain solid.

  • Page 17: Balance Control

    4.11 Balance Control When playing CD+G tracks with multiplex vocals included rotating the balance control clockwise reduces the vocals. Rotating the balance control anti-clockwise reduces the backing track. When playing non-multiplex CD+G tracks or standard stereo tracks rotating the balance control anti-clockwise or clockwise pans stereo audio from the left &...

  • Page 18: Bluetooth Audio

    find the last paired device, the display and the Bluetooth status indicator will keep flashing. Turn on the Bluetooth function of your device and enable the search until “GOODMANS KARAOKE ” is found. Select It on the Bluetooth device to make connection.

  • Page 19: Troubleshooting

    Troubleshooting Problem What to do No power when DC plug of the AC adapter is not plugged POWER ON/OFF into the DC JACK properly. BUTTON is pressed The AC outlet may not have power. No power when Check the outlet with a working lamp or plugged in other electrical appliance.
  • Page 20 Source Selection on your TV/home stereo is not set properly. Select AV INPUT as the source for your No sound - If TV/home stereo. audio is going through TV/ Improper connection to stereo system. home stereo Follow directions on ‘Audio Connection’ section for connecting to a home stereo system.

  • Page 21: Technical Specifications

    Technical Specifications 339562 Model Numbel AC/DC adapter (Included) Input: AC 100 – 240V ~ 50/60Hz AC /DC Operation Output: DC 9V 2.0A Speaker Output PAL composite (RCA) Video Output Max 32 GB (FAT32 formatted) USB Flash Drive Support Each 6.3 mm (mono) Microphone Jacks 3.5 mm (stereo)
