1.FEATURES Camera Full HD indoor fisheye IP camera (Vandal proof) High quality compression in real time streaming 1/2.7” 1080p CMOS Image Sensor 180˚ wide and 160˚ vertical angle Remote Zoom/Focus Control(One Click AF) Streaming Dual streaming mode (such as different codec/resolution/bit rate and so on.) ...
2. PACKAGE CONTENTS Unpack carefully and handle the equipment with care. The packaging contains: Camera DC power adapter Quick installation guide 9-pin and 2-pin terminal blocks FMB mount (for flush mount) Screws and anchors The above contents are subject to change without prior notice. Note www.rivatech.de...
3. PART NAMES ① ② *This button is located under PCB. ⑤ ③ ④ ⑥ * Models and their appearance are subject to change without any prior notice. 1. Reset button The reset button can be used for restarting the device or resetting it to Factory Default.
Page 7
5. Connections for more details. Video out is used only for installation and works for 3 minutes when PAL/NTSC button is pushed. 4. LAN connector RJ45 LAN connector for 10/100 Base-T Ethernet. 5. MicroSD Slot Slot for the MicroSD card 6.
4. INSTALLATION 4.1. Option A. Semi-Flush Mount Installation template image’s size scale in this installation guide is not 1:1. The correct-size template design paper can be found inside the Caution package separately. www.rivatech.de...
Page 9
Place the installation template on a surface where camera is going to be installed and mark the anchor block placements. 2) Drill and insert anchor blocks on a marked surface. 3) Mount the main camera body by aligning the anchor blocks and hold against the mounting surface..
4.2. Option B. Flush Mount Installation template (FMB) 21 V1.0 Installation template image’s size scale in this installation guide is not 1:1. The correct-size template design paper can be found inside the Caution package separately. www.rivatech.de...
Page 11
Trace the size on a surface where the device will be inserted with the provided template and create a hole. Also, mark on a surface where anchor blocks will be inserted. 2) Drill and insert anchor blocks on a marked surface. Connect all the appropriate cables to the main device and place on the center of the hole.
To prevent products from damaging, place the camera on stable and non-vibrating surfaces. If the stability is in doubt, consult with safety personnel for reinforcements, and then proceed with the Caution installation. 4.3. Setting the Image Attribute Through the camera’s webpage, users can configure image settings. The camera image’s brightness, contrast, saturation and sharpness are adjustable through the image settings.
Reset N / A N / A 5. CONNECTIONS N / A N / A VIDEO AUDIO DC12V ETHERNET MICRO SD ⑥ N / A N / A 1. Audio input/output The camera has a mono audio input and a mono audio output. Due to low audio output power, an amplified speaker is recommended for enhanced sound (Do not connect a N / A N / A...
Page 14
Do not exceed the maximum input voltage or relay rate. Caution Internal Internal +3.3V Output of Output of Sensor Sensor Relay Type Voltage Type 3. Alarm (DO) connection Only the relay type is supported. Relay Rating: Max 24VDC 50mA Do not exceed the maximum relay rating. Caution Internal Device...
Page 15
4. Video input/output The camera provides 1 video out Video Black 5. LAN connection This is a RJ45 LAN connector for 10/100 Base-T Ethernet. Connect a LAN cable. Green LED Orange LED When the device is connected, the orange LED stays on while green LED continues to blink.
6.CONFIGURATION 6.1.Set up network environment The default IP address of the device is 192.168.XXX.XXX. Users can identify the IP address of the device from converting the MAC address’s hexadecimal numbers, which is attached to the device. Be sure that the device and PC are on a same area network before running the installation.
6.1.2. Custom IP Environment IPAdminTool and the manual are provided on USB stick or can download from homepage. www.rivatech.de IPAdminTool is a management tool, which automatically scans all of the network products for users to perform administrative tasks, which includes network configurations, firmware update, device reboot, and device organizations.
3. In the IP Setup’s window, information under ‘Local Network information’ displays the user/PC’s network area information. Those information need to be incorporated to the IP Address, Subnet Mask, Gateway, and DNS boxes, except the last 2 sets of IP Address, which are to be the unique numbers for the device. Refer to the image above for the setting 4.
Page 19
3. Follow the instructions of the dialog boxes and complete the installation. Once the installation is complete, start the web browser again and check if video stream is displayed in the main view frame. This software requires the Microsoft XML Parser V6 or higher. If “...
6.2.1. View video using IPAdmin Tool IPAdminTool automatically searches all activated network encoders and IP cameras and shows the product name, IP address, MAC address and etc. IPAdminTool is provided on USB stick or can download from homepage. www.rivatech.de 1. From the IPAdminTool’s product list, select the device by highlighting it. 2.
6.3. Reset 1. Push the Reset button and hold for 1~2 seconds. 2. Wait for the system to reboot. 6.4. Factory Default If you reset your device to the factory default setting, all parameters including the IP address will be initialized. To proceed back to the Factory Default reset: 1.
APPENDIX (B): POWER OVER ETHERNET The Power over Ethernet (PoE) is designed to extract power from a conventional twisted pair Category 5 Ethernet cable, conforming to the IEEE 802.3af Power-over- Ethernet (PoE) standard. IEEE 802.3af allows for two power options for Category 5 cables. The IEEE 802.3af-2003 standard allows up to 15.4 W power to device.
APPENDIX (D): HEXADECIMAL- DECIMAL CONVERSION TABLE Refer to the following table when you convert the MAC address of your device to IP address. www.rivatech.de...
