Parallel Compensation; Field Overvoltage Protection; Field Overcurrent Protection; Exciter Diode Monitor (Edm) Protection - Basler DECS-200 Instruction Manual

Accuracy
FCR Mode:
Var Mode:
Power Factor Mode:
Internal Tracking:

Parallel Compensation

Modes:
Burden: ∗
Adjustment Range
Reactive Droop:
Reactive Differential:

Field Overvoltage Protection

Pickup
Range:
Increment:
Time Delay
Range:
Increment:

Field Overcurrent Protection

Pickup
Range:
Increment:
Time Delay
Characteristic:

Exciter Diode Monitor (EDM) Protection

Pole Ratio
Range:
Increment:
Ripple Threshold
Open and Shorted Diode:
Time Delay
Open Diode Protection:
Shorted Diode Protection:
Open and Shorted Diode Inhibit Levels
Range:

Generator Undervoltage Protection

Pickup
Range:
Increment:
Time Delay
Range:
Increment:
DECS-200
±1.0% of the nominal value for 10% of the bridge input voltage change or
20% of the field resistance change. Otherwise, ±5.0%.
±2.0% of the nominal VA rating at the rated frequency
±0.02 PF of the PF setpoint for the real power between 10 and 100% at
the rated frequency.
0.5%
Reactive Droop and Reactive Differential (cross-current) ∗
Can exceed 1 VA if external resistors are added to the CT circuit for
crosscurrent compensation.
0 to 30%
–30 to 0%
1.0 to 325 Vdc
1.0 Vdc
0.2 to 30 s
0.1 s
0 to 16 Adc
0.1 Adc
Inverse per ANSI C50.13
1 to 10 (0 if unknown)
0.01
0 to 100%
10 to 60 s
5 to 30 s
0 to 100% or <1 Adc field current
<45 Hz and >70 Hz generator frequency
0 to 30 kVac
1.0 Vac
0.5 to 60 s
0.1 s
General Information 1-7
