- Page 1 User Manual MMX6464 PTN Modular Matrix Switcher 64x64 All Rights Reserved Version: MMX6464_2015V2.2 www.PTN-electronics.com...
- Page 2 Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without the prior written consent of PTN Electronics Limited. FCC Statement This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Safety Precautions
Unplug the power cord when left unused for a long period of time. Information on disposal for scrapped devices: do not burn or mix with general household waste, please treat them as normal electrical wastes. PTN Electronics Limited www.PTN-electronics.com... -
Page 4: Table Of Contents
Modular Matrix Switcher 64x64 Table of Contents 1. Introduction ......................... 1 1.1. About MMX6464 ....................1 1.2. Features ......................1 1.2.1. MMX signal card (changeable cards) ............. 1 1.4 Package List ...................... 2 2. Panel Description ......................3 2.1. MMX6464 ......................3 2.1.1. - Page 5 5.2.6. 4I-SD & 4O-SD ..................28 5.2.7. 4I-TP & 4O-TP ..................29 5.2.8. 4I-UH & 4O-UH ..................29 5.2.9. 4I-UF & 4O-UF ..................30 5.2.10. 4I-BT & 4O-BT ..................31 6. Troubleshooting & Maintenance ................32 7. After-sales Service ....................34 PTN Electronics Limited www.PTN-electronics.com...
-
Page 6: Introduction
It has RS232 port for serial control and optional IP port for TCP/IP control, can be easily controlled by third-part devices. With its flexible design, MMX6464 can be used for different project and tend to be an all-in-one solution. It is the combo solution for multimedia conference rooms, control rooms, broadcasting rooms, shopping center etc. -
Page 7: Package List
4O-UF Optical Fiber 4O-BT HDBT, RS232, Audio 1.4 Package List 1 x MMX6464 1 x RS232 cable 4 x Plastic cushions 1 x IR remote (The cell battery is not included) 1 x Power Cord ... -
Page 8: Panel Description
Modular Matrix Switcher 64x64 2. Panel Description 2.1. MMX6464 2.1.1. Front Panel Figure 2- 1 Front Panel of MMX6464 Name Description ① IR sensor, receive IR signal sent from IR remote Power Illuminate red once powered on ② indicator Display real-time operation status ③... -
Page 9: Rear Panel
UNDO: Undo button, to resume to the status before the command just performed. : Backspace button, to backspace the latest input button. 2.1.2. Rear Panel Figure 2- 2 Rear Panel of MMX6464 Name Description ① INPUTS Input signal card slots, 16 in total Output signal card slots, 16 in total ②... -
Page 10: Changeable Cards
⑥ connector Note: There are only 16 input and 16 output slots for MMX6464, which enables only 16 input cards and 16 output cards to be installed on MMX6464. The input/output cards can be changed based on your requests and supports hot plug and play. -
Page 11: Ds& 4O-Ds
It is embedded the EDID management technology, supporting DDC. It is also compatible with DVI signal (HDCP required). 4I-HD: input card, maximum four input signal. Input signal can pass to output device through 4O-HD, or pass through other kinds of output cards. PTN Electronics Limited www.PTN-electronics.com... -
Page 12: Vg & 4O-Vg
4I-VG: input card, maximum four input signal. Input signal can pass to output device through any kinds of output cards. 4O-VG: output card, maximum four VGA output signal and 4 stereo audio outputs, output video signal from 4I-VG, or other kinds of input cards, and output audio signal PTN Electronics Limited www.PTN-electronics.com... -
Page 13: I-Va
Scale all inputs to 1080p. Compatible with C-Video, YUV, YC (Factory preset function). Supporting RGBHV, RGsB, RGBS, RsGsBs, YUV, YC and Composite video. 4I-VA: input card, maximum four VGA inputs and four stereo audio inputs. Input signal PTN Electronics Limited www.PTN-electronics.com... -
Page 14: Sd & 4O-Sd
Support HDTV, compatible with HDMI1.3 and HDCP 4I-TP: input card, maximum input four HDMI TP signal. Input signal can pass to output device through 4O-TP, or pass through other kinds of output cards, need to work with TPHD402T. PTN Electronics Limited www.PTN-electronics.com... -
Page 15: Uh & 4O-Uh
HDMI embedded audio. It is also embedded the EDID management technology. 4I-UH: input card, maximum four input signal. Input signal can pass to output device through 4O-UH, or pass through other kinds of output cards. PTN Electronics Limited www.PTN-electronics.com... -
Page 16: Uf & 4O-Uf
It is also embedded the EDID management technology. 4I-BT: input card, maximum input four HDMI TP signal. Input signal can pass to output device through 4O-BT, or pass through other kinds of output cards, need to work with HDBT transmitter (e.g. TPHD402T). PTN Electronics Limited www.PTN-electronics.com... -
Page 17: System Connection
1) System should be installed in a clean environment and has a prop temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated and safe. 3) All devices should be connected before power on. PTN Electronics Limited www.PTN-electronics.com... -
Page 18: Connection Diagram
3.2. Connection Diagram Figure 3- 1 System Diagram 3.3. Application MMX series has a good application in various occasions, such as radio & television, multi-media meeting room, big screen displaying, television education and command & control center etc. PTN Electronics Limited www.PTN-electronics.com... -
Page 19: Control Operations
Modular Matrix Switcher 64x64 4. Control Operations Users can control MMX6464 rapidly and directly with its front panel buttons. To switch AV/ A/ V signal, please operate the buttons under the following format: Format: “Input Channel” + “AV” +“Output Channel”+“Enter”... -
Page 20: Ir Remote Control
Modular Matrix Switcher 64x64 4.1. IR Remote control With the IR remote, MMX6464 could be controlled remotely. As the function buttons on the IR remote are the same with the ones on the front panel, the IR remote shares the same operations and commands with the control panel. -
Page 21: Rs232 Control
4.2. RS232 Control 4.2.1. Connection of RS232 Communication Port Except the front control panel and IR remote, MMX6464 can be controlled by far-end control system or through the Ethernet control via the RS-264 communication port. This RS-264 communication port is a female 9- D connector. The definition of its pin layout is shown in the table below. - Page 22 EDID file (.bin file). Upgrade EDID data of input ports When the switcher gets the command, it will EDIDUpgrade[x]. show a message to send EDID file (.bin file). Operations will be canceled after 10 seconds. PTN Electronics Limited www.PTN-electronics.com...
- Page 23 Set the resolution of input [x] to USER/I/[x]:0621%; 1600X1200@60Hz. Set the resolution of input [x] to USER/I/[x]:0629%; 1920X1080@60Hz. Set the resolution of input [x] to USER/I/[x]:0620%; 1920X1200@60Hz. Restore to factory default. USER/I/[x]:0617%; Auto-adjust VGA signal USER/I/[x]:0606%; PTN Electronics Limited www.PTN-electronics.com...
- Page 24 Set the resolution of input [x] to 1280x720, 720P USER/I/[x]:0627%; Set the resolution of input [x] to 1280x800, USER/I/[x]:0628%; WXGA Set the resolution of input [x] to 1920x1080, USER/I/[x]:0629%; 1080P Set the resolution of input [x] to 1920x1200, USER/I/[x]:0620%; WUXGA PTN Electronics Limited www.PTN-electronics.com...
- Page 25 3. Please remember to end the commands with the ending symbols “.” or “;”. 4. Type the command carefully, it is case-sensitive. 5. Commands pertaining to EDID only avails for signal cards that support EDID management. PTN Electronics Limited www.PTN-electronics.com...
- Page 26 Example: “12B12,13,15.” to transfer signal from the input12 to the output No.12,13,15. 9、Inquire the input channel to the output channel [x]: Status[x]. Example: Send “Status3.” to inquire the input channel to the output 3. 10、Inquire the input channel to the output channels one by one: Status. PTN Electronics Limited www.PTN-electronics.com...
- Page 27 Example: “EDIDM5B3.” to enable input 3 to learn the EDID data of output 5. 15、Command for signal cards: USER/[Y]/[X]*****. Example: “USER/I/7:0623%;” to set the input 7 to support YPbPr signal, the card is plugged in the second input slot of the matrix. PTN Electronics Limited www.PTN-electronics.com...
-
Page 28: Tcp/Ip Control (Optional)
Controlled by PC(s) in LAN The MMX6464 can be connected with a router to make up a LAN with the PC(s), this make it able to be controlled in a LAN. When control, just make sure the MMX6464’s IP section is the same with the router. -
Page 29: Tcp/Ip Settings
Step3. Set the MMX6464’s IP address and gateway to the same IP section as the router. Step4. Set the PC’s IP address and gateway as the original one. Step5. Connect the MMX6464 and PC(s) to the router. In the same LAN, each PC is able to control the MMX6464 asynchronously. 4.3.2. TCP/IP Settings Step1. -
Page 30: Specification
RS-232, 9- female D 2 = TX, 3 = RX, 5 Serial control port Configurations connector = GND Front panel Installation Rack Mountable Buttons control Options TCP/IP control General Power Supply 100VAC ~ 240VAC, Power 550W (Max) PTN Electronics Limited www.PTN-electronics.com... -
Page 31: Changeable Cards
Connector output T.M.D.S. Input Level T.M.D.S. 2.9V~3.3V Level 2.9V~3.3V Input Output 75Ω 75Ω Impedance Impedance General 340 MHz (10.2 Gain 0 dB Bandwidth Gbit/s) Switching Video Signal DVI,HDMI,VGA,C-VIDEO,YPbPr 200ns (Max.) Speed 5nS (±1nS) Crosstalk <-50dB@5MHz Time-delay PTN Electronics Limited www.PTN-electronics.com... -
Page 32: Hd & 4O-Hd
0.5 ~ 2.0Vp-p Input Output 75Ω 75Ω Impedance Impedance General 350MHz (-3dB), fully Gain 0 dB Bandwidth load VGA-UXGA, RGBHV, RGBS, RGsB, RsGsBs, component video, Video Signal S-video & C-video. Switching 200ns (Max.) Crosstalk <-50dB@5MHz Speed PTN Electronics Limited www.PTN-electronics.com... -
Page 33: Sd & 4O-Sd
<-14 dB @ 1 MHz ~ Loss Loss 1.5 GHz SMPTE 292M, SMPTE Video 259M, SMPTE 424M, Data Type 8bit, 10bit Standard ITU-RBT.601, ITU-RBT.1120 Audio Bits per 18 bits per channel, 2 channels (L, R) Sample PTN Electronics Limited www.PTN-electronics.com... -
Page 34: Tp & 4O-Tp
Output Video Output Audio Output Output 4 HDMI Output 4 Stereo Output Output 3.5mm Stereo audio Female HDMI Connector Connector connector Min.～Max. Output 75Ω T.M.D.S. 2.9V~3.3V Level Impedance Output Frequency 20Hz～20K Hz 100Ω (Differential) Impedance Response PTN Electronics Limited www.PTN-electronics.com... -
Page 35: Uf & 4O-Uf
Up to 4Kx2K Resolution 1km (Single mode transmission, using Single Mode Optical Transmission Module and OM3 Single Mode Fiber Cable) Distance 300m (Multi-mode transmission, using Single/ Multi mode Optical Module and OM3 Multi-Mode Fiber Cable) Data Rate 10.2Gbit/s PTN Electronics Limited www.PTN-electronics.com... -
Page 36: Bt & 4O-Bt
Humility >70dB@ Return Loss <-30dB@ 5KHz 100MHz-100M Supported Embedded HDMI audio: PCM, Dobly Digital, DTS, DTS-HD Audio Format Analog audio: PCM HDMI Support HDMI1.4 Standard EDID& HDCP Compliant with HDCP 1.4; Support manual EDID management Management PTN Electronics Limited www.PTN-electronics.com... -
Page 37: Troubleshooting & Maintenance
Static becomes stronger Check the grounding and when connecting the video Bad grounding make sure it is connected connectors well. PTN Electronics Limited www.PTN-electronics.com... - Page 38 Send it to authorized by RS232 / IR remote / been broken. dealer for repairing. front panel buttons If your problem persists after following the above troubleshooting steps, seek further help from authorized dealer or our technical support. PTN Electronics Limited www.PTN-electronics.com...
-
Page 39: After-Sales Service
Modular Matrix Switcher 64x64 7. After-sales Service If there appear some problems when running MMX6464, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: PTN warrants that its products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 40 PTN Electronics Limited Tel: +86-755-2846 1819 Fax: +86-755-8471 7796 Email: info@PTN-electronics.com Website: www.PTN-electronics.com...
