Instruction Manual
D103409X012
Figure 2‐4. FIELDVUE DVC6205 Base Unit with Mounting Bracket (Rear View)
72
(2.82)
10C1796‐A
Figure 2‐5. FIELDVUE DVC6205 Base Unit Wall Mounting
X0428
57
(2.25)
2 MOUNTING
HOLES
j 8.6 (0.34)
MM
(INCH)
SPACER
1‐INCH 1/4‐20
HEX HEAD
SCREW
MOUNTING BRACKET
Installation
May 2013
15
