Error Codes
Error
Error Message
Number
Line/ box too
44
wide
Rotation out of
45
range
Scale factor
46
wrong
Bar lines
47
overflow
48 Bad bar style
49
Bad bar width
50
Bad bar ratio
51 Bad bar human
52
Bad bar csum
53
Bad bar speed
54
Bad bar data
Graphic To
55
Wide
56
X underflow
57
X overflow
58
Y underflow
59
Y overflow
Timeout in
60
Binary
Timeout in
61
format
Note: -
X and Y overflows. Do not use Arial Black type font. The Codesoft WYSIWYG is incorrect
when using this Font.
Note: -
The first error shown with in the Mini Terminal is the fault. Any other error faults shown on
the display, maybe generated because of this fault shown.
January 2011
Reason
Box design incorrect
Incorrect Rotation set in the
Format should be 0,1,2 or 3
Graphic Scaling factor
incorrect should be 0,1 or 2
Incorrect barcode design.
Selected a non-supported
Barcode type.
Bar width larger than 5 or
less than 2.
Ratio within the Barcode
Format design incorrect.
Available Ratios are 0 =3,1=
2.5 & 2= 2
Human readable is larger
than 1
Check Digit value larger than
1
Incorrect Speed flag. Should
be Zero
Barcode data to many or few
digits for the barcode type.
Check Type of Barcode,
whether numerical or
Alphabetical or both.
Graphic to wide for the
printer. Graphic file
corrupted?
Format design is out side the
Print area, on the left side of
the "X" axis.
Format design is out side the
Print area, on the right side of
the "X" axis.
Format design is out side the
Print area, at the top of the
page on the "Y" axis.
Format design is out side the
Print area, at the bottom of
the page on the "Y" axis.
1. Incorrect Baud Rate Set
2. Noise on the
Communication lead
3. Incorrect Network number
set. (Network printers only)
1. Information in the Format
Design, missing or
incorrect
2. Network number set in the
Printer. But not in
Codesoft.
Corrective Measures
Correct the Format design. The fault can only be
created in Dos.
Correct the Format with correct rotation. The fault
can only be created using Dos.
Correct the Format design.
Correct the barcode design. The fault can only be
created in Dos.
Check the type of Barcode required. The fault can
only be created in Dos.
Bar width Maximum 5, Minimum 2. The fault can
only be created in Dos.
Correct the Format design. The fault can only be
created in Dos.
Human readable maximum 1 Minimum 0. The fault
can only be created in Dos.
Check digit Maximum 1, Minimum 0. The fault can
only be created in Dos.
Correct the Barcode design. The fault can only be
created in Dos.
Change the number of digits to suit the Barcode
type, check the style of barcode and the data
needed.
Resize or replace the graphic
Move the Format design to be with in the Print
area.
Move the Format design to be with in the Print
area.
Move the Format design to be with in the Print
area.
Move the Format design to be with in the Print
area.
1. Check the Baud Rate
2. Check the communication lead.
3. Check the Network number.
1. Correct the Format Design. Other error
generated
during the download of the format or fonts.
2. Set the Printer Network number to Zero if no
Network. Then re-boot the Printer.
If networked, set network number in Codesoft.
