Ethernet & USB-B Board
Ethernet & USB-B Board (Setting Instructions)
Description
Foreword
TCP/IP, Transmission Control Protocol / Internet Protocols
Port Number
Changing System Variables using Codesoft
Codesoft Communications Ethernet (now known as TCP/IP)
Changing System Variables using Recovermode
Recovermode Communications
Changing System Variables using Termode
Termode Communications
(
Issue 1.03)
Thermocode Series 2
Ethernet is known as TCP/IP in this manual.
11 January 2010
Open Date Equipment Ltd.
Unit's 8 & 9 Puma Trade Park,
145 Morden Road,
Mitcham,
Surrey.
CR4 4DG
Tel: - 0044 (0) 20 8655 4999
Fax: - 0044 (0) 20 8655 4990
http://www.opendate.co.uk/
Page No- 1 -
Page
2
2
2
3 – 5
6
7
8 – 9
10 – 11
11 - 12

Advertisement

loading
Need help?

Need help?

Do you have a question about the Thermocode 2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Open Date Thermocode 2 Series

Summary of Contents for Open Date Thermocode 2 Series

  • Page 1 Ethernet & USB-B Board Issue 1.03) 11 January 2010 Page No- 1 - Open Date Equipment Ltd. Unit’s 8 & 9 Puma Trade Park, 145 Morden Road, Mitcham, Surrey. CR4 4DG Tel: - 0044 (0) 20 8655 4999 Fax: - 0044 (0) 20 8655 4990 http://www.opendate.co.uk/...
