Chappee NXR3 Installation Manual page 11

Stud M 10 x 90
Guide
Screw TH M 10 x 30
Stud M 10 x 90
Stud M 10 x 90
Guide
Screw TH M 10 x 30
Stud M 10 x 90
Fig. 10
Top insulation blanket
Rear insulation
blanket
Fig. 12
Front
Insulation positioning
Front insulation blanket
Stud M 10 x 90
Door hinge and door guide
Hinge
Screw TH M 10 x 30
Screw TH M 10 x 30
Hinge
Stud M 10 x 90
Stud M 10 x 90
Hinge
Screw TH M 10 x 30
Screw TH M 10 x 30
Hinge
Stud M 10 x 90
4 holes M 8 equidistant on a perforation Ø of 170
4 holes M 10 equidistant on a perforation Ø of 200
4 holes M 14 equidistant on a perforation Ø of 254
11
assembly
Pre-drilled
burner door
Fig. 11
Side insulation
blanket
Bottom insulation blanket
Ref. : CH - 1249 - A - 2
