NEC NVM-DFx Manual page 10

Programming a Subscriber's Mailbox
6) When you are done editing the Email Options for this Subscriber mailbox, click
7) Repeat the steps above for each Subscriber mailbox that you want to integrate
6
■
Email Name - The Email address where the voice mail will be received.
■
Smtp Server - Name or IP Address of the SMTP Server
■
Domain Name - The SMTP domain name if available. Otherwise, leave this
field blank.
■
Smtp Port - Normally, the port number will be 25. If a Secure Socket Layer
(SSL) is being used, enter 465 as the port number.
■
Smtp SSL - Secure Socket Layer. If this feature is enabled, make sure that
465 is entered as the port number.
■
Smtp Authentication - Authentication code (if required by the ISP)
■
Smtp Account - The Email address for this subscriber, for example -
petera@ctlinc.com
■
Smtp Password - The password that would normally be used to by this
subscriber to access his Email
■
Imap4 Server - Name or IP Address of the SMTP Server
■
Imap4 Port - Normally, the port number will be 143.
■
Imap4 SSL - N/A
■
Imap4 Account - The Email address for this subscriber
■
Imap4 Password - The password that would normally be used to by this
subscriber to access his Email
■
Imap4 Authentication - Authentication code (if required by the ISP)
■
Imap4 Search Mode - The Client PC periodically polls the Email server
during the synchronization process. This is done, for example, to make sure
that the same message is deleted from the Email server when it is deleted
from the Client PC. This field determines whether the Email is searched for
by Header or Text.
the Apply changes button.
with the Email server.
NVM-DFx - SMTP Email Integration
