Zoomax Snow 7 HD Manual

Color portable video magnifier
Hide thumbs Also See for Snow 7 HD:
Table of Contents

Advertisement

Quick Links

See also: User Manual
ZOOMAX
Snow 7 HD
ZOOMAX Technology Co., Limited
©
®
Copyright
2013 ZOOMAX Technology Co., Limited. All Rights Reserved. ZOOMAX
is a
trademark of ZOOMAX Technology Co., Limited in the United States and other countries.
Information in this document is subject to change without notice. No part of this publication
may be reproduced or transmitted in any forms or by any means electronic or mechanical,
for any purpose, without the express written permission of ZOOMAX.
If you have any question or suggestion concerning the use of this product, please contact
your distributor or ZOOMAX by e-mail sales@zoomax.co.
To search the knowledge base, please visit www.zoomax.co and choose the relative links.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snow 7 HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zoomax Snow 7 HD

Summary of Contents for Zoomax Snow 7 HD

  • Page 1 2013 ZOOMAX Technology Co., Limited. All Rights Reserved. ZOOMAX is a trademark of ZOOMAX Technology Co., Limited in the United States and other countries. Information in this document is subject to change without notice. No part of this publication may be reproduced or transmitted in any forms or by any means electronic or mechanical, for any purpose, without the express written permission of ZOOMAX.
  • Page 2 2. Less than 500g (17.64 ounces), truly lightweight brings you the maximum possibility to use Snow 7 HD freely anywhere, no matter at home or on the go. 3. The ergonomic design of Writing Stand gives you sufficient writing space to write greeting card or signing name on the check or bills quickly.

  • Page 3: Table Of Contents

    ZOOMAX Snow 7 HD Content Accessories ............................. 1 Compositions ..........................2 Operation ............................4 Charge the battery ........................4 Turn on/off ........................... 6 Adjust magnification ........................7 Select color mode........................8 Freeze ............................11 Writing instruction ........................12 Turn on/off the sound ....................... 13 Turn on/off the LED lights ......................
  • Page 4 ZOOMAX Snow 7 HD Connect to TV/monitor ......................16 Power saving function ......................16 Disable power saving function....................16 Setting memory function ......................18 Close/Far-view function ......................19 Frame Rate Setting ........................20 Troubleshooting ..........................21 Safety ............................. 22 Technical specifications ....................... 24...

  • Page 5: Accessories

    ZOOMAX Snow 7 HD Accessories You would find the following contents inside the Snow 7 HD package box: 1. Snow 7 HD video magnifier 2. One piece of Protective Pouch 3. User’s Guide 4. HDMI Cable 5. Power Adapter 6. One piece of Cleaning Cloth...

  • Page 6: Compositions

    ZOOMAX Snow 7 HD Compositions Freeze Button 7-inch LCD Screen Color Mode Button Power Indicator Zoom In Button Zoom Out Button Stand Power Button...
  • Page 7 ZOOMAX Snow 7 HD Far/Close-view Switch HDMI Port USB Port (For firmware update only) Power Input Port...

  • Page 8: Operation

    Operation Charge the battery - The battery MUST be fully charged prior to FIRST use of your Snow 7 HD. - Connect the supplied Power Adapter to the Power Input Port and plug the other end of Power Adapter into Power Outlet. The Power Indicator is RED while charging.
  • Page 9 - Charging the battery takes approximately 4~5 hours. Your Snow 7 HD can be continuously used up to 5 hours after fully charged.

  • Page 10: Turn On/Off

    8 seconds and the image on Snow 7 HD appears subsequently. - To turn off your Snow 7 HD, please press and hold Power Button for 2 seconds (Note: you would see the Power Indicator goes off.)

  • Page 11: Adjust Magnification

    Zoom Out Button - Press the “ ” button to zoom in and press the “—” button to zoom out. - When you keep Snow 7 HD flat on the reading material (see Figure 1), the magnification ratio is 2.2X ~...

  • Page 12: Select Color Mode

    ZOOMAX Snow 7 HD - Under close-view mode, lift your Snow 7 HD at a certain distance from the reading material will decrease the magnification. Connect the unit to TV screen will increase the magnification. Select color mode Color Mode Button 1.
  • Page 13 ZOOMAX Snow 7 HD - Full color - Grey mode - High contrast white text on black background mode - High contrast black text on white background mode - High contrast white text on blue background mode - High contrast blue text on white background mode...
  • Page 14 ZOOMAX Snow 7 HD 2.Favorite mode - Under any contrast color mode, except of full color and grey mode, long press Color Mode Button for 2 seconds. And you hear one Beep. It enters into Favorite mode. Only 3 color modes are for selection in Favorite mode.

  • Page 15: Freeze

    - Place your Snow 7 HD over the viewed material. (Please keep the viewed material on flat). - Press Freeze Button to capture an image you need. - Take your Snow 7 HD closer to your eyes to see the image. The image can be zoomed in/out or changed color mode.

  • Page 16: Writing Instruction

    ZOOMAX Snow 7 HD Writing instruction Stand (Figure 1) - Open the stand. - Write under the camera (See Figure 1)

  • Page 17: Turn On/Off The Sound

    - By default, the button sound is off but the beep sound is always ON. - To turn on the button sound, please make sure your Snow 7 HD at the LOWEST magnification. Press and hold the “—” button for 7 seconds until you hear ONE Beep.

  • Page 18: Turn On/Off The Led Lights

    ZOOMAX Snow 7 HD Turn on/off the LED lights Color Mode Button - By default, the LED lights are ON under close-view mode and OFF under far-view mode. - Under Normal mode: 1. When in high contrast color (except of full color and grey color), please press and hold the Mode Button for 5 seconds until you hear TWO Beeps to turn on/off LED light.

  • Page 19: Adjust The Screen Brightness

    ZOOMAX Snow 7 HD - Under Favorite mode: Press and hold the Mode Button for 5 seconds until you hear TWO Beeps to turn on/off LED light. Adjust the screen brightness - Press the Freeze Button and Zoom in Button simultaneously until the brightness bar appears.

  • Page 20: Connect To Tv/Monitor

    ZOOMAX Snow 7 HD Connect to TV/monitor - Plug HDMI cable into your Snow 7 HD and TV. Then, the screen of Snow 7 HD will turn off automatically and switch to HDMI output mode. Power saving function - By default, your Snow 7 HD turns off automatically if non-use in 3 minutes.
  • Page 21 Freeze Button to enter into demo mode. A small icon will appear at the lower left of the screen. Under demo mode, after you turn on your Snow 7 HD, it is always ON unless you turn it off.

  • Page 22: Setting Memory Function

    Snow 7 HD Setting memory function - When you turn off your Snow 7 HD, the most recent settings is saved automatically (e.g. color mode, magnification, video output format, button beeps, brightness, favorite mode, normal mode) .So you can easily use the memorized settings while turn on your Snow 7 HD again.

  • Page 23: Close/Far-View Function

    - Toggle the Far/Close-View Button to view close/far. (See Figure 1) - Toggle the button to the Right direction to view Close. - Toggle the button to the Left direction to view distance. - Turn your Snow 7 HD UPSIDE DOWN to view distance more comfortably. (See Figure 2)

  • Page 24: Frame Rate Setting

    ZOOMAX Snow 7 HD Frame Rate Setting (Remark: this is only needed when indoor lighting with fluorescent lamps interferes with the frame rate of the unit.) - Press and hold the Freeze Button for 3 seconds to enter into Frame Rate Setting. Press “+”...

  • Page 25: Troubleshooting

    ZOOMAX Snow 7 HD Troubleshooting Problems Solutions ●Ensure that the power is on. ●Charge the battery. Black screen ●Decrease the magnification level. ●Ensure the image is below the crosshair. The unit will not turn on. ●Charge the battery. The image on the screen is ●Ensure the unit is flat on the viewed material.

  • Page 26: Safety

    ZOOMAX Snow 7 HD material. The unit is connected to a TV, ●Ensure the TV is on. but no image appears on the ●Check the line is proper and output and connection TV screen. correctly to TV. The screen is frozen or ●Long press Mode and Power buttons together to...
  • Page 27 ZOOMAX Snow 7 HD - Do not use your video magnifier to excessive heat or direct sunlight to avoid the risk of fire. - Keep your video magnifier away from wet areas, rain, fluids and chemicals. -Do not use your video magnifier around inadequately shielded medical devices.

  • Page 28: Technical Specifications

    ZOOMAX Snow 7 HD Technical specifications 1. Magnification: 2.2X ~ 2. High contrast color modes: 12 modes (3 favorite color modes) - Full color - Grey mode - White text on black background mode - Black text on white background mode...
  • Page 29 6. Viewing distance: 6.5cm ~ 500cm (2.56 ~ 196.85 7. Functions: Freeze image, Switch color mode, Zoom in/out 8. Settings saved after power-off 9. Power-Saving: Snow 7 HD turns off automatically if non-use in 3 minutes 10. Connect to TV/Monitor 11. Power adapter: Input: 110—240V Output: 5V/2.5A...
  • Page 30 ZOOMAX Snow 7 HD NOTES...
