Bus assignment features
In addition to providing full variable send capabilities in the Mix section, the X-Monitor also
offers audio grouping facilities for sending input signals to the output matrix section, and
directly to the A and B output masters for creating additional mixes. All assignments are
normally derived Post-fader(post-eq and post-mute).
Bus assignments 13, 14, 15 & 16
The input signal is assigned to Buses 13 thru 16 which feed Matrix 1 - 4, located above
the master control section.The feed to Buses 13-16 is normally Post-fader.All Bus 13-16
sends (from Inputs and Groups) can be globally switched to Pre-fader by using the 13-16
PRE switch, located in the Master section.
A Bus assignment
The Input signal is assigned to the main A output bus.This feed is always Post-fader.
B Bus assignment
The Input signal is assigned to the main B output bus.This feed is always Post-fader.

Input fader

The 100mm channel fader is the primary level control for all Post-fader signals being sent
to any of the console's mix buses.The fader offers greater than 90dB of attenuation and up
to 10dB of boost . Normal operation is between -10 and 0.
Solo switch
Pressing this momentary switch will include (illuminate) or exclude (not-illuminated)
the channel from the consoles solo system. See Master Control Section for information on
Solo options.
