Installation

Installation and Maintenance Details

Fastening screw
for the shelf
frame
Minipack Sliding Drawer Shelf
in Operation Position
Fastening screw
for the shelf frame
F1, F2...Plastic
Cover
Minipack Sliding Drawer Shelf
in Maintenance Position
Minipack
blind cover
Front handle
4

Opening or Closing the Minipack Drawer Shelf

To access the Minipack distribution area, you have to open the
Fastening screws
sliding drawer shelf. Do following to open or close the drawer:
for the drawer
1. Unlock the drawer shelf by
2. Open or close the drawer shelf by
3. Lock the drawer shelf by
Shelf
Frame

Mounting or Removing Minipack Blind Covers

1. Unlock the blind cover by
2. Insert or remove the blind cover by
3. Lock the blind cover by
Locking screw
to secure the blind cover
using a screwdriver to loosen the upper and lower locking
screws. Do not loose the screw in the middle!
holding the drawer from the side plates and sliding it
outwards.
The drawer shelf is the in the Maintenance Position.
or
sliding it on its mounting rail fully into the shelf
screwing home the upper and lower locking screws.
The drawer is then securely locked in the shelf, in its
Operation Position
using a screwdriver to loosen the locking screw
sliding it on its mounting rail fully into the power shelf
or
sliding it out, by inserting your fingers in the cover's front
handle and pulling it loose
screwing home the locking screw (locked direction).
Then, the blind cover will be securely locked in the shelf,
or ready for transport
Quick Start Guide Minipack PS System
Details
356808.103, v1-2006-12
