PRODUCT REPRESENTATION
DUAL DRIVER SUBWOOFER (TYPICAL)
Models: IS8-212, IS8-215, IS8-218, IS6-212, IS6-215, IS6-218
IS8-218
EQUIPMENT BASICS
Mounting Points
(M10 Flat Head Screws)
Page 5
Grille
Aluminum Grille
Retainer
Quick Start Guide
Dual Sub Input Panel
Mounting Points
(M10 Flat Head Screws)
Note: Weather-resistant (WR)
models are ordered
preconfigured for single or
multi-amp connections and have
a sealed cover over the input
panel. A 12 ft (3.6m) 14 ga cable
though a sealed gland nut is
provided for connection to the
amplifier.
Input panel
Jumper
Mounting Points
(M10 Flat Head Screws)
I SERIES IP800/IP600, IS800/IS600
