to the minimum position. If the burner does not remain lit, increase the minimum gas rate setting.
The procedure for adjusting the minimum gas rate setting is described below.
Auxiliary, semi-rapid and rapid burners:
• Light the burner.
• Set the gas valve to the "minimum rate" position.
• Remove the knob.
• Using a screwdriver turn the screw "F1" until adjustment is correct (fig. 15c).
Inside crown of DUAL burner:
• Light the DUAL burner.
• Set the gas valve to the "minimum rate" position of the inner crown only.
• Remove the knob.
• Using a screwdriver turn the screw "F3" until the correct setting is obtained (fig. 15d).
Outside crown of DUAL burner:
• Light the DUAL burner.
• Set the gas valve to the "minimum rate" position of the inner + outer crowns.
• Remove the knob.
• Using a screwdriver turn the screw "F2" until the correct setting is obtained (fig. 15d).
Normally for ULPG, the regulation screw is tightened up.
Auxiliary,
Semi-rapid and
Rapid burners
F1
F
J
Figure 15a
Figure 15c
J
Injectors for
Injector for
outer crown
inner crown
F2
F3
Dual burner
J
Figure 15b
Figure 15d
