  • Page 1 PROSOURCE EN Installation and user manual GYB 00416UT GYB 00816UT...
  • Page 2 Image 1 Main components of the complete system...
  • Page 3 ImagEs Image 2 Parts description...
  • Page 4 2 www.aeg.com...
  • Page 5 ImagEs...
  • Page 6 4 www.aeg.com Image 3 Before installation...
  • Page 7 ImagEs Image 4 Overview Solo Situation...
  • Page 8 6 www.aeg.com Image 5 Overview Combi Situation...
  • Page 9 ImagEs Image 6 The tap Installed...
  • Page 10 8 www.aeg.com Image 7 The filter installed (optional)
  • Page 11 ImagEs Image 8 Attach t-piece to cold water supply Image 9 Place discharge connection on siphon...
  • Page 12 10 www.aeg.com Image 10 Attach bracket with 4 screws Image 11 Attach the safety valve to the mixing valve using the adapter and seal...
  • Page 13 ImagEs Image 12 Place discharge con nection on siphon...
  • Page 14 12 www.aeg.com Image 13 Attach discharge connection to siphon Image 14 Connect filter hose...
  • Page 15 ImagEs Image 15 Connect cold water hose to filter and pressure safety valve...
  • Page 16 14 www.aeg.com Image 16 Connect cold water hose to t-piece and safety valve (situation without filter)
  • Page 17 ImagEs Image 17 Connect cold water inlet boiler to pressure safety valve Image 18 Connect cold water inlet boiler to mixing valve...
  • Page 18 16 www.aeg.com Image 19 Connect boiling water hose boiler to boiling water inlet tap...
  • Page 19 ImagEs Image 20 Connect boiling water extension hose...
  • Page 20 18 www.aeg.com Image 21 Connect boiling water inlet tap to mixing valve...
  • Page 21 ImagEs Image 22 Connect cold water inlet tap to t-piece...
  • Page 22 20 www.aeg.com Image 23 Connect warm water inlet tap to warm water supply...
  • Page 23 ImagEs Image 24 Connect warm water inlet tap to warm water outlet mixing valve...
  • Page 24 22 www.aeg.com Image 25 Use boiling water handle PUSH...
  • Page 25 ImagEs Image 26 Image 27 Use mixing handle 1 Use mixing handle 2...
  • Page 26 24 www.aeg.com Image 28 Built-in dimensions 8.3” 8.3” 6.8”...
  • Page 27 ImagEs 6.6” 9.3” 6.6” 9.3” 5” 5.6” 4.2”...
  • Page 28: Table Of Contents

    8. TECHNICAL INFORMATION .................42 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
  • Page 29: Introduction

    1. INTRODUCTION 1.1 Intended use and 1.2 general working unintended use principle This AEG appliance is intended to be This AEG appliance stores, heats and used to store, heat and provide provides boiling drinking water in drinking water. The appliance should addition to cold and warm water.
  • Page 30: Safety Information

    28 www.aeg.com 1.3 article numbers The table below describes the available components of the appliance. main parts Type article number Boiler 4 litres GYB00416UT 8 litres GYB00816UT Curve – Chrome finish GYT11012CB Square – Chrome finish GYT12012CB Curve – Stainless steel finish GYT11012SB Square –...
  • Page 31 AC wall socket only at the • The appliance may only be used end of the installation. Make sure together with the original AEG tap. that there is access to the plug and • Make sure to place all parts correctly earthed AC wall socket after the and according to the instructions.
  • Page 32 2.10 Repair, disassemble, • The filter installation kit and replacement water filter cartridges discard can be ordered online at shop.aeg. com, part code: 9029795565. • Only qualified, certified personnel may repair, disassemble or discard 2.8 Use the appliance. Disconnect the...
  • Page 33: Product Description

    ENGLISH 2.11 Procedure in the event reused, depending on the capacity of your boiler. of breaks in operation • After a shutdown of 4 weeks or more, the filter cartridge must be • After a break in operation exceeding replaced by a new one. Refer to the two days (weekend, holiday, etc.), manual of the filter for more the appliance must be flushed with...
  • Page 34 32 www.aeg.com 3.3 main components tap (see image 2) Part Description Spout Fastening set Cold water inlet (blue woven hose) Warm water inlet (red woven hose) Boiling water inlet (red label) Boiling water handle with safety system Mixer handle 3.4 main components pressure safety valve (see image 2)
  • Page 35 ENGLISH 3.5 main components mixing valve (for combi situation only; see image 2) Part Description Boiling water inlet or outlet (indicated by “H”) Boiling water inlet or outlet (indicated by “H”) Warm water outlet (indicated by “MIX”) Cold water inlet (indicated by “C”) Cold water outlet Seal Cold water inlet...
  • Page 36: Installation

    34 www.aeg.com 4. INSTALLATION 4.1 Important installation information • Read and follow all instructions in the SAFETY INFORMATION section. • Refer to the separate manuals supplied with the other components for more relevant information. 4.2 Before installation step action Make sure that you have the following installed in your kitchen cabinet (see image 3): • Discharge pipe with siphon (Ø...
  • Page 37 ENGLISH step action Install the tap. – Install the tap (B) according to the instructions supplied with the tap (see image 6). Optional: install the filter – If you need a filter, install the filter (E) according to the instructions supplied with the filter (see image 7).
  • Page 38 36 www.aeg.com step action Connect the pressure safety valve. If you are using a filter: – Connect one end of the filter hose (40) to the t-piece (14) and the other end to the water inlet of the filter (37) (see image 14).
  • Page 39 ENGLISH step action Connect the cold water. – Connect the cold water inlet of the tap (8) to the t-piece (14) (see image 22). NOTICE! The cold water inlet of the tap (8) is the blue woven hose. Connect the warm water. If you install the solo configuration: –...
  • Page 40: Daily Use

    38 www.aeg.com 4.5 starting the boiler step action Connect the plug of the boiler (3) to the earthed AC wall socket. CAUTION! Extension cables and multi-plug adapters are not permitted between the electrical socket and boiling water storage heater connection.
  • Page 41 ENGLISH 5.2 Using the boiling water tap The boiling water tap has a handle with safety function enabled with a pressure and rotation motion. The handle retracts if released and locks automatically. WaRNINg! Temperature of water delivered by boiling water tap can be very hot and can cause scalding! To open and close the boiling water tap: step...
  • Page 42: Maintenance, Care And Cleaning

    40 www.aeg.com 6. MAINTENANCE, CARE AND CLEANING 6.1 Important care and cleaning information • Read and follow all instructions in the SAFETY INFORMATION section. • Refer to the separate manuals supplied with the other components for other relevant care and cleaning information.
  • Page 43 ENGLISH Problem Cause solution The red LED light The boiler is not filled with This is a locked error on the boiler water and is turned on (dry- and can only be reset by flashes every 0.5 on situation). unplugging the power seconds.
  • Page 44: Technical Information

    42 www.aeg.com Problem Cause solution Flow rate too high Too much pressure • Close the valve of the pressure safety valve (23) or the cold water supply valve. • Place a pressure reducing valve Water drips from • Replace the expansion...
  • Page 45 ENGLISH 8.4 sanitary data 4 litre 8 litre Capacity boiler Minimum water supply pressure 0.15 MPa (1.5 bar) Maximum water supply pressure 0.4 Mpa (4 bar) Flow rate boiling water at Solo configuration: Approx. 2.2 l/min 0,15 MPa (1.5 bar) flow pressure Combi configuration: Approx.
  • Page 48 www.aeg.com/shop...
