Rotex HPSU compact 508 Instruction Manual page 61

Hot water volume without
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
50 °C)
Hot water volume without
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
60 °C)
Heat technics
Hot water volume without
power data
re=heating at tapping rate
(8 l/min /12 l/min)
(TKW = 10 °C/TWW = 40 °C/TSP =
65 °C)
Reheating time (Wh) with a draw-off
quantity:
140 l = 5820 Wh (Ø bathtub
draw-off quantity)
90 l = 3660 Wh (Ø shower draw-off
quantity)
Cold and hot water
Pipe connections
Heating feed and return flow
Refrigerant circuit
Number of circuits
Liquid line
Pipe connections
Gas lines
Operating data
Outdoor tempera-
ture range for
room heating/
Operating range
cooling function
Water heating
Audibility
(1
Noise level
Acoustic pressure
BA ROTEX HPSU compact 2 - 04/2011
Unit
l/min
l/min
l/min
l/min
inches
inches
Number
Type inches
External diameter inches
Type
External diameter inches
Heating
°C
(min./max.)
Cooling
°C
(min/max)
Heating
°C
(min./max.)
dBA
dBA
HPSU compact 508
338 / 272
527 / 468
614 / 560
45
30
1" outer thread
1" internal thread
1
2
Flanged connection
1/4" outer thread
Flanged connection
5/8" outer thread
-20 to 25
10 to 43
15 to 50
42
29
8 x Technical data
HPSU compact 516
338 / 272
527 / 468
614 / 560
25
17
1" outer thread
1" internal thread
1
2
Flanged connection
3/8" outer thread
Flanged connection
5/8" outer thread
-25 to 35
10 to 46
15 to 55
46
32
61
