Pin Assignments

Keyboard Wedge Connector (To Host Side):
Pin
1
2
3
4
5
6
Mini-DIN 6P Female Connector
Mini-DIN 6P Male Connector
RS-232 DB-9F Connector (To Host Side):
Pin
1
2
3
4
5
6
7
8
9
Mini-DIN 6P Male
DATA / PC
NC
GND
VCC (+5V)
CLK / PC
NC
Definition
NC
TXD
RXD
NC
GND
NC
CTS
RTS
VCC (+5V)
Mini-DIN 6P Female
CLK / KB
GND
DATA / KB
VCC (+5V)
NC
NA
5
9
4
8
3
7
2
6
1
