PRODUCT OVERVIEW
Waveform Assistant
A Vital Companion Product to the Popular Enhanced Diagnostic Lead Set (EDLS)
How many times have
you been in this
situation —
"I wonder what the wave-
form of this component
should look like?"
Instant access to known good
waveforms saves time and helps
accuracy.
The dual channel oscilloscope
can display Crank and Cam
signals together!
Compare yours to the library.
The Waveform Assistant includes
a Waveform Library that holds over 30
known good waveforms, including
Oxygen Sensor, Throttle Position
Sensor, and Manifold Absolute
Pressure Sensor. It may be just what
Primary Ignition signals are
easily reviewed using one of
the many waveforms stored in
the waveform library.
What should a normal oxygen
sensor waveform look like? Now
you can easily display a known
good pattern.
13
you need to diagnose a stubborn
problem. You can display these
waveforms whenever you need, such
as during a component test. They
were captured from real vehicles, like
those that you work on every day.
EDLS enables quick view of
secondary ignition signals for
efficient diagnosis.
View secondary ignition
waveforms (single and all
cylinders) to help diagnose
troublesome ignition systems.
