- Page 1 Hikvision Technical Manual DS-1004CDY Mobile DVR Caddy Device Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved. Lo-Call 1890 866 900 www.cctvireland.ie shop@cctvireland.ie...
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Hikvision Technical Manual Contents 1. Overview 2. Model Description 3. Hardware Interface 4. Specifications ©2006 – 2010 by HIKVISION. All rights reserved. Lo-Call 1890 866 900 www.cctvireland.ie shop@cctvireland.ie...
- Page 4 Hikvision Technical Manual 1. Overview HIKVision Mobile Removable Caddy is designed especially for mobile DVR of pluggable hard drives. It is used to backup the recorded video files. It is simple and convenient to use. This Caddy plugs into DS-1004HMI, after you...
-
Page 5: Model Description
Hikvision Technical Manual 2. Model Description The Removable caddy: support 2 SATA HDD interface, support USB 2.0 interface. A factory recommended HDD should be used for this device. ©2006 – 2010 by HIKVISION. All rights reserved. Lo-Call 1890 866 900 www.cctvireland.ie shop@cctvireland.ie... - Page 6 Hikvision Technical Manual 3. Hardware Interface 1. USB DVR Interface ©2006 – 2010 by HIKVISION. All rights reserved. Lo-Call 1890 866 900 www.cctvireland.ie shop@cctvireland.ie...
-
Page 7: Specifications
1 DVR Sata interface Power supply DC +12V Power consumption 2W (without HDD) Working temperature -10° C~+55° C Working humidity 10%~90% Size 132mm(W)*182mm(H)*41mm(D) Weight ≤0.4Kg (without HDD) ©2006 – 2010 by HIKVISION. All rights reserved. Lo-Call 1890 866 900 www.cctvireland.ie shop@cctvireland.ie...
