- Page 1 DS-9500 Series NVR Quick Operation Guide Version 1.3.1...
-
Page 2: Verify Contents
Please contact your dealer for damaged or missing items. NVR Pre-Installation The DS-9500 Series NVR is highly advanced surveillance equipment that should be installed with care. Please take into consideration the following precautionary steps before installation of the NVR. 1. Keep all liquids away from the NVR. -
Page 3: Front Panel
DS-9500 Series NVR Quick Operation Guide Front Panel DS-9508NI-S/R Front Panel Name Description Turning red indicates power supply but without system running, turning blue Power indicates power supply and system running. Status Alarm Alarm indicator turns red when a sensor alarm is detected. -
Page 4: Rear Panel
DS-9500 Series NVR Quick Operation Guide HDD indicator blinks red when data is being read from or written to HDD. Ready Ready indicator turns blue when NVR is functioning properly. Backup Backup indicator blinks blue when data is being backup. - Page 5 DS-9500 Series NVR Quick Operation Guide DS-9516NI-S/R Rear Panel: Item Description RESET Press and hold it for 10 seconds to reset all parameters to factory defaults RS-232 Connect to RS-232 devices 10/100/1000Mbps Self-adaptive UTP Ethernet interface. eSATA Backup/extended storage interface, connect to external SATA disk, CD-RW, disk array, etc.
-
Page 6: Alarm Connections
DS-9500 Series NVR Quick Operation Guide Relay alarm input Relay alarm input To connect to an AC/DC load, use the following diagram: Relay alarm output For DC load, JP4 can be used within the limit of 12V/1A safely. If the interface is connected to an AC load, JP4 should be left ope n. -
Page 7: Specifications
DS-9500 Series NVR Quick Operation Guide Specifications DS-9500NI-S: Model DS-9508NI-S DS-9516NI-S 8-ch 4CIF /4-ch 720P /2-ch 16-ch 4CIF /8-ch 720P /4-ch UXGA /1080P real time, or UXGA /1080P real time, or 8-ch Video/Audio input IP video input 4-ch UXGA /1080P /2-ch 5... - Page 8 DS-9500 Series NVR Quick Operation Guide DS-9500NI-R: Model DS-9508NI-R DS-9516NI-R 8-ch 4CIF /4-ch 720P /2-ch 16-ch 4CIF /8-ch 720P /4-ch UXGA /1080P real time, or UXGA /1080P real time, or 8-ch Video/Audio input IP video input 4-ch UXGA /1080P /2-ch 5...
-
Page 9: Hdd Storage Calculation Chart
DS-9500 Series NVR Quick Operation Guide HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K... -
Page 10: Basic Operation
Apply power to the unit and the POWER LED indicator on the front panel will light in green, which indicates the unit is powered on. Note: DS-9500 series NVR do not provide local output, when the POWER and LINK LED indicators light normally, it indicates the unit has been successfully started and connected to network. Shutdown Unplug the power cord to shut down the unit. - Page 11 DS-9500 Series NVR Quick Operation Guide Select a device from the list and then click the Select Device button to add the device. User can also click the Modify button to modify the subnet mask, IP address and device port of the device, and then input the user name and password for login, and finally click Save to complete the modification.
-
Page 12: Add Device
DS-9500 Series NVR Quick Operation Guide On the top right corner, language is selectable between Chinese and English. Input the correct user name, password and port, click Login to enter preview interface, or it will pop up an error box. The default user name is admin, password is 12345, and port is 8000. - Page 13 DS-9500 Series NVR Quick Operation Guide Refer to the following table for the number of IP cameras which can be added at different resolution: Model Name IP camera connections DS-9508NI-S/R Up to 8-ch 4CIF or 4-ch 720P or 2-ch UXGA IP cameras...
- Page 14 DS-9500 Series NVR Quick Operation Guide Select the IP camera from the list to be added and then click OK to finish the adding. Single Adding of IP Camera This function enables you to add a single IP camera quickly. When there are supported IP cameras in the same network segment of a LAN with NVR, you may add it in one button with default user name, password and port number.
- Page 15 DS-9500 Series NVR Quick Operation Guide Preview After login, the preview interface will display: When live preview, the windows division can be selected by click the button on play control area. It can support 1 and 4 windows division. The change between different windows division modes will not stop the current preview;...
-
Page 16: Start/Stop Recording
DS-9500 Series NVR Quick Operation Guide Preview by device: Click the device node on the list, then multiple channels will start to be displayed synchronously on the selected window divisions. When the 1-window division mode is selected, click to switch to the next window, or click to the previous window for preview. -
Page 17: Schedule Recording Settings
DS-9500 Series NVR Quick Operation Guide Note: If the free space in the defined disk is less than 500M, the web server will stop recording automatically. Click button on playlist to start recording of this channel, and if the icon is not , it will prompt “Recording... - Page 18 DS-9500 Series NVR Quick Operation Guide Select one day in a week, and select All Day Recording if necessary. You may also set period recording by disable All Day Recording; there are 8 time periods in one day. Then you can select schedule recording from the drop-down menu beside the periods.
