OPERATING MANUAL 사용설명서 操作手册 操作手冊 ASSEMBLY 조립 组装 組裝 clik WASH FILTER Wash filter with cold water at least every month. month 필터 청소 개월 최소한 한 달에 한 번 찬물로 个月 個月 필터를 세척해 주십시오. 清洗过滤器 用冷水清洗过滤器 至少每月一次。 FULLY CHARGED 완전...
Page 2
After registering your free 2 year guarantee, your Dyson 在登记2年免费保修之后, 自购买之日起, 依据保修条款, 您 handheld vacuum will be covered for parts and labour for 的戴森手提式真空吸尘器将享有2年零件和人工保修。 2 years from the date of purchase, subject to the terms of 如果您对戴森手提式真空吸尘器有任何疑问, 请致电戴森客 the guarantee.
Dyson vacuum or charger. Do not install, charge or use the Dyson vacuum outdoors, in a bathroom or within 10 feet of a pool. Do not use the Dyson vacuum or charger on wet surfaces and do not expose to moisture, rain or snow. Do not use to pick up water.
Page 4
중요 안전 지침 이 제품을 사용하거나 배터리를 충전하기 전에 충전기, 배터리, 다이슨 청소기와 사용설명서에 있는 모든 지침사항을 읽어 주시기 바랍니다. 전자 제품을 사용할 때는 다음을 포함한 기본 안전 주의사항을 반드시 준수해야 합니다. 경고 화재, 감전, 부상의 위험을 줄이기 위해서: 다이슨 휴대용 청소기는 신체적, 감각적 능력 또는 정신적 능력이 부족한 사람, 또는 경험이나 지식이 부족한 사람 (어린이...
Page 7
Marking for naMe & Content of toxiC or Hazardous substanCes or eleMents 有毒有害物质或元素名称及含量标识 toxic or Hazardous substances or elements 有毒有害物质或元素 Part name 部件名称 Cadmium lead Mercury Hex Chromium Pbde 镉 (Cd) 铅 (Pb) 汞 (Hg) 六价铬 (Cr6+) 多溴联苯 多溴联苯醚 external chassis, body 外部机壳,机身...
Page 8
Looking for blockages • 막힌 부분 찾기 Power • 전원 • 电源 • 電源 查找阻塞物 • 檢查阻塞 MAX POWER 최대 전력 最大功率 最大電源消耗功率 HIGH CONSTANT SUCTION 고성능의 지속 흡입력 高速恒定吸尘 持續特強吸力 clik Combination accessory tool • 컴비네이션 툴 • 组合附件工具 • 組合工具 clik...
Page 9
Charging • 충전중 • 正在充电 • 充電中 Too cold/too hot - do not use 온도가 너무 낮거나 높은 곳에서 사용하지 마십시오 太冷或太热时不可使用 太冷 或 太熱時不可使用 Charging 충전중 正在充电 充電中 Fully charged 완전충전 完成充电 完全充電 Not charging – check battery 충전중 아님 - 배터리 점검 未充电-检查电池...
USING YOUR DYSON HANDHELD VACUUM • The filter may require more frequent washing if vacuuming fine dust or used mainly in ‘HIGH CONSTANT SUCTION’ power mode. CAUTION: • Do not use detergents to clean the filter. • Do not put the filter in the dishwasher, washing machine, tumble dryer, oven, • Do not allow the Dyson handheld vacuum cleaner to be used by anyone who microwave or near an open flame. may not be able to operate it safely. • Take caution not to engage battery release button during normal operation. LOOKING FOR BLOCKAGES • Dirt and debris may be released from the Dyson handheld vacuum if it is turned upside down. Ensure the Dyson handheld vacuum remains upright in use CAUTION: and storage. • Switch ‘OFF’ the Dyson handheld vacuum and disconnect from charger before • Do not operate the Dyson handheld vacuum while checking for blockages. looking for blockages. Failure to do so could result in personal injury. • Do not use outdoors or on wet surfaces or to vacuum water or other liquids – • Beware of sharp objects when clearing blockages. electric shock could occur. • Refit all parts of the Dyson handheld vacuum securely before using. PLEASE NOTE: PLEASE NOTE: •...
Dyson handheld vacuum is found to be defective due to faulty materials, workmanship or function within 2 years of purchase or delivery (if any part is no longer available or out of manufacture Dyson will replace it with a functional replacement part).
Page 14
• 다이슨 휴대용 진공 청소기 사용하기 미세 먼지를 흡입한 경우 필터를 보다 자주 청소해야 할 수 있습니다. • 필터 세척 시 세제를 사용하지 마십시오. 주의: • 필터를 식기 세척기, 세탁기, 탈수기, 오븐, 전자레인지에 넣거나 불꽃 주변에 • 다이슨 휴대용 진공 청소기를 안전하게 작동할 수 없는 사람이 사용하도록 두지...
Page 15
보증합니다. 다이슨 휴대용 진공 청소기에 대해 질문이 있으시면 제품 일련번호와 휴대용 진공 청소기를 구입한 장소 및 시기에 대한 구체적인 정보를 준비하셔서 다이슨 헬프라인으로 연락해 주시기 바랍니다. 일련번호는 필터 뒤에 있습니다. 대부분의 질문은 전화 상으로 저희 다이슨 헬프라인의 직원이 해결해 드릴 수 있습니다. 대한민국에서 판매되는 정식수입제품의 경우제품출고 시 2년 품질 보증 절차가 자동으로이루어집니다. 다이슨 진공 청소기 사용자로 등록하십시오. 다이슨 휴대용 진공 청소기를 구입해 주셔서 감사드립니다. 신속하고 효율적인 서비스를 받을 수 있도록 하기 위해, 다이슨 진공 청소기 사용자로 등록하시기 바랍니다. 등록은 다음과 같이 두 가지 방법이 있습니다: 이메일 등록 CN: servicejcpc@jebsen.com HK: pidcs@jebsen.com KR: dyson@cosmoco.co.kr MY: dysonsupport@visionary.com.my TW: service@hlh.com.tw 다이슨 고객 서비스 헬프라인에 전화 등록 이를 통해 보험 손실의 경우 다이슨 휴대용 진공 청소기의 소유권을 확인할 수 있고, 필요한 경우 연락을 받을 수 있습니다. 2년 제한 보증 보증 범위 구입 또는 배송 후 2년 이내에 귀하의 다이슨 휴대용 진공 청소기에서 제조 상의 문제, 재질 상의 결함, 기능 상의 결함이 발견된 경우 (다이슨의 자체 판단에 따라) 귀하의 다이슨 휴대용 진공 청소기의 수리나 교체(부품을 더 이상 확보할 수 없거나 생산이 중단된 경우에는 기능 상 교체 가능한 부품으로 교체). • 다이슨 휴대용 진공 청소기를 구매한 국가 내에서의 사용. •...
Page 20
Helpline with your serial number and details of where and when you bought the cleaner, or contact us via the Dyson website. The serial number can be found on the main body of the vacuum cleaner behind the clear bin.
