BRC2E52C7
BRC3E52C7

Table of contents

Operation .......................................................................................... 1
1. General safety precautions ............................................................... 1
2. Features and functions ..................................................................... 1
3. Name and function of switches ......................................................... 2
4. Name and function of icons .............................................................. 2
5. Description of the operation modes .................................................. 3
6. Basic operation method .................................................................... 3
7. Description of the items in the main menu........................................ 4
8. Airflow Direction ................................................................................ 4
9. Individual Air Direction ...................................................................... 4
10. Quick Start (SkyAir Only) .................................................................. 5
11. Ventilation (HRV only)....................................................................... 5
12. Energy Saving Options ..................................................................... 5
13. Schedule ........................................................................................... 5
14. Filter Auto Clean ............................................................................... 5
15. Maintenance Information .................................................................. 5
16. Configuration..................................................................................... 6
17. Current Settings ................................................................................ 6
18. Clock & Calendar .............................................................................. 6
19. Language .......................................................................................... 6
20. Error code display ............................................................................. 6
21. Main menu structure ......................................................................... 6
Installation ......................................................................................... 7
1. General safety precautions ............................................................... 7
2. What is in the box ............................................................................. 7
3. Fasten the remote controller ............................................................. 7
4. Wire the indoor unit........................................................................... 7
5. Attach the upper case ....................................................................... 8
6. Remove the upper case.................................................................... 8
7. Power on........................................................................................... 8
8. Enable/Disable the Menu/Enter and Cancel Button.......................... 9
Maintenance...................................................................................... 9
1. General safety precautions ............................................................... 9
2. Filter sign resetting............................................................................ 9
Appendix ......................................................................................... 10
The original instructions are written in English. All languages are
translations of the original instructions.
Refer to http://www.daikineurope.com/support-and-manuals/product-
information/ for more detailed Operation and Installation Manuals.

Operation

1. General safety precautions

WARNING
Also see Operation Manual attached to the outdoor and
indoor unit.
Please read these "General safety precautions" carefully before
installing the remote controller.
Failure to follow these instructions properly may result in property
damage or personal injury, which may be serious depending on the
circumstances.
WARNING
Do NOT play with the unit or its remote controller.
Accidental operation by a child may result in impairment of
bodily functions and may harm health.
Quick reference
1
Wired remote controller
Page
WARNING
Never disassemble the remote controller. Touching the
interior parts may result in electric shocks or fire. Consult
your Daikin dealer or authorized contractor for internal
inspections and adjustments.
WARNING
To avoid electric shocks, do not operate with wet hands.
WARNING




2. Features and functions

The state of the art remote controller offers full control over your
installation.
1 BASIC REMOTE CONTROLLER
The basic remote controller functions are:
 ON/OFF,
 operation mode change-over (only for BRC2E),
 temperature adjustment,
 fan speed adjustment,
 airflow direction adjustment.
2 CLOCK FUNCTION
The clock functions are:
 12/24 hours real time clock,
 automatic daylight saving time.
3 SCHEDULE FUNCTION
The schedule timer function is disabled in case the BRP7A51
Digital Input Adapter is installed.
The schedule timer functions are:
 a maximum of 5 actions can be programmed for each day of
the week,
 3 independent schedules can be programmed,
 schedule can be enabled/disabled at any time,
 linked to a cool temperature and/or heat temperature or an
OFF operation (with or without a setback temperature),
 "last Command" overrules previous command until next
scheduled command.
Do NOT modify or repair the remote controller. This
may result in electric shocks or fire. Consult your
Daikin dealer.
Do NOT relocate or reinstall the remote controller by
yourself. Improper installation may result in electric
shocks or fire. Consult your Daikin dealer.
Do NOT use flammable materials (e.g. hairspray or
insecticide) near the product. Do not clean the product
with organic solvents such as paint thinner. The use of
organic solvents may cause crack damage to the
product, electric shocks, or fire.
Quick reference
BRC2E52C7+BRC3E52C7
Wired remote controller
4P368040-1 - 2014.02
