Philips Vision duet HR8982 Service Manual

! !
Service Service
Information Information
Philips Domestic Appliances and Personal Care
Service Manual

PRODUCT INFORMATION

- Maximum air displacement
- Maximum vacuum water column
- Power consumption (IEC)
- Dust storage capacity
- Cord length
- Filter system (depends on version) : Paper dustbag
- Dimensions cleaner
- Weight without accessories
- Noise
OPTIONAL
Exhaust air fi lter HR 6932 (8836 932 01210)
Oslo cotton dustbag HR 6935 (8836 935 01010)
Oslo paper dustbag set HR 6938 (8836 938 06110) economy
Oslo paper dustbag set HR 6938 (8836 938 10110) hygiene
Oslo 3-M dustbag HR 6938 (8836 938 91010)
Active carbon inlet fi lter HR 6949 (8836 949 01010)
Active carbon fi lter set HR 6968 (items 41 + 42)
S-class fi lter HR 6992 (8836 992 01010)
S-class fi lter set HR 6993 (items 48 + 49)
Accessory kit : HR 8000
HR 8001
HR 8002
HR 8003
HR 8004
HR 8005
HR 8006
This product meets the requirements regard-
ing interference suppression on radio and TV.
Published by Philips Domestic Appliances and Personal Care
4322 277 00236
00/02
PCS 101 379
Vision Duet
: 37 l/sec.
: 310 cm
: 1500W
: 4 litres
: 8.3 metres
: Exhaust air fi lter
: Motor inlet fi lter
: 48 x 30 x 25 cm
: 6.4 kg
: 78 dB
standard
standard plus
clean and shine
easy reach
clean and polish
clean and brush
animal
Printed in the Netherlands

Vacuum cleaner

SERVICE INFORMATION

- The infrared remote control can adjust the suction power with
5 speeds. When switched on, the appliance always starts
with the highest power, even without a connected hose.
Use LR03 batteries. Alkaline is advised.
- To open the appliance, fi rst remove the panel (item 13) with a big
screw driver (V) to disconnect the 4 snap locks (the 4 screws of
button panel item 39 can be loosed) and then remove the two
pedals (items 1 and 14) with a pin (W), max. diameter 2.5 mm.
- Power meter (8838 000 60300) is a commercial item with a fi xed
air displacement which measures the vacuum of the appliance.
- Component confi guration on exploded view may differ in case
of specifi c versions. However, the actual components are
distinguished by means of code numbers.
- The spare parts have been standarized as much as possible.
- Item 7A. This appliance is provided with ring 7A. For other parts
use item 6 or 7.
- Item 16 Cotton dustbag is used in those countries where paper
dustbags are not available.
- Item 21 is provided with the long cord-winder spring; both long
and short cords can be used in combination with this spring.
- To disassemble the cordwinder use TORX screw driver no T15,
which is one of a set consisting of T20, T15, T10, T9, T8, T7 and
T6 = 4822 395 50145.
- Item 43 air valve opens to cool the motor if the air displacement is
too low or if the air fl ow is blocked.
After the product has been repaired, it should
function properly and has to meet the safety
requirements as offi cially laid down at this
moment.
© Copyright reserved
HR 8982
Subject to modification
