1-12 GENERAL INFORMATION
Item
CRANKSHAFT / CONROD
Conrod small end
STD
inside diameter
STD
Conrod big end oil
clearance
Limit
Conrod big end
STD
inside diameter
Crank pin outside
STD
diameter
Crank pin outside
Limit
diameter difference
Conrod bearing
STD
thickness
STD
Conrod big end side
clearance
Limit
Conrod big end width
STD
Crank pin width
STD
Crankshaft center
Limit
journal runout
STD
Crankshaft journal
oil clearance
Limit
Crankcase bearing
STD
holder inside diameter
Crankshaft journal
STD
outside diameter
Crankshaft journal
outside diameter Limit
difference
Crankshaft bearing
STD
thickness
STD
Crankshaft thrust
clearance
Limit
Crankshaft thrust
STD
bearing thickness
LOWER UNIT
Design specification thickness for shim & washer.
Pinion gear back-up shim
Forward gear back-up shim
Forward gear thrust washer
Reverse gear thrust washer
Reverse gear back-up shim
Unit
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
mm (in)
Data
DF60T
16.968 – 16.979 (0.6680 – 0.6685)
0.020 – 0.050 (0.0008 – 0.0020)
0.080 (0.0031)
45.000 – 45.018 (1.7717 – 1.7724)
41.982 – 42.000 (1.6528 – 1.6535)
0.010 (0.0004)
1.484 – 1.502 (0.0584 – 0.0591)
0.10 – 0.25 (0.004 – 0.010)
0.35 (0.014)
21.95 – 22.00 (0.864 – 0.866)
22.10 – 22.20 (0.870 – 0.874)
0.06 (0.002)
0.016 – 0.036 (0.0006 – 0.0014)
0.060 (0.0024)
56.000 – 56.018 (2.2047 – 2.2054)
51.982 – 52.000 (2.0465 – 2.0472)
0.010 (0.0004)
1.998 – 2.014 (0.0787 – 0.0793)
0.11 – 0.31 (0.004 – 0.012)
0.38 (0.015)
2.47 – 2.52 (0.097 – 0.099)
1.00 (0.039)
1.00 (0.039)
3.0 (0.12)
2.2 (0.09)
1.5 (0.06)
DF70(W)T/70WTH
