Inserting and Removing 8000 Series Modules

Inserting a Module or Slot Cover

Inserting a Module or Slot Cover
Version 5.2
To remove a module or slot cover:
1. Remove and reserve the T8 Torx screw from the lever of the module using
the included screwdriver.
Screw
Lever
2. Pull the lever away from the module to release the latch.
3. Slide the module out of the slot.
Remove the existing module or slot cover to prepare the slot for a new module.
See Removing a Module or Slot Cover
Sourcefire 3D System User Guide
on page 259 for more information.
Appendix C
260
