Hardware Specifications
Sourcefire Defense Centers
Serial VGA
Port Port
DC3500 System Components: Rear View
F
EATURE
PS/2 mouse
connector
PS/2 keyboard
connector
VGA port
USB ports
RJ45 serial port
10/100/1000Mbps
Ethernet
management
interface
Alternate eStreamer
interface
Redundant power
supplies
Version 5.2
DC3500 Chassis Rear View
The rear of the chassis contains the connection ports and power supplies.
Management Interface
USB Alternate eStreamer Interface
Ports
The DC3500 System Components: Rear View
appear on the rear of the appliance.
D
ESCRIPTION
Allows you to attach a monitor, keyboard, and mouse to the appliance, as an
alternative to using the RJ45 serial port, to establish a direct
workstation-to-appliance connection. You also must use a USB port to restore
the appliance to its original factory-delivered state, using the thumb drive
delivered with the appliance.
Allows you to establish a direct workstation-to-appliance connection (using an
RJ45 to DB-9 adapter) for direct access to all of the management services on
the appliance. The RJ45 serial port is used for maintenance and configuration
purposes only and is not intended to carry service traffic. See the
Serial Port Pin Assignments table
IMPORTANT! You cannot use the front and the rear panel serial ports at the
same time.
Provides for an out-of-band management network connection. The
management interface is used for maintenance and configuration purposes
only and is not intended to carry service traffic.
Provides an alternate interface for the eStreamer client
Provides power to the appliance through an AC power source
Sourcefire 3D System Installation Guide
table describes the features that
on page 140.
Chapter 6
Power Supplies
DC3500
