Hardware Specifications
Sourcefire 7000 Series Devices
3D7115 and 3D7125 SFP Optical Parameters
P
ARAMETER
Optical connectors
Bit rate
Baud rate/encoding/tolerance
Optical interface
Operating distances
Transmitter wavelength
Maximum average launch power
Minimum average launch power
Maximum average power at receiver
Receiver sensitivity
Management Interface
Version 5.2
Use the following table to understand the specifications of the SFP optical
transceivers.
3D7115 and 3D7125 Chassis Rear View
The rear of the chassis contains the management interface, connection ports,
grounding studs, and power supplies.
3D7115 and 3D7125 (Chassis: GERY-1U-8-4C8S-AC) Rear View
Reserved USB 2.0 Ports
VGA Port
Sourcefire 3D System Installation Guide
1000BASE-SX
LC duplex
1000Mbps
1250Mbps /
8b/10b encoding
Multimode
200 m (656 ft) for
62.5 μm/125 μm fiber
500 m (1640 ft) for
50 μm/125 μm fiber
770-860 nm
(850 nm typical)
0 dBm
-9.5 dBm
0 dBm
-17 dBm
Grounding Studs
Serial Port ID LED
Chapter 6
1000BASE-LX
LC duplex
1000Mbps
1250Mbps /
8b/10b encoding
Single mode only
10 km (6.2 miles) for
9 μm/125 μm fiber
1270-1355 nm
(1310 nm typical)
-3 dBm
-11.5 dBm
-3 dBm
-19 dBm
Power Supply LEDs
Redundant Power Supplies
