Hardware Specifications
Sourcefire 8000 Series Devices
Version 5.2
Use the 1000BASE-SX NetMod Optical Parameters
optical specifications of the fiber interfaces.
1000BASE-SX NetMod Optical Parameters
P
ARAMETER
Optical connectors
Bit rate
Baud rate/encoding/tolerance
Optical interface
Operating distances
Transmitter wavelength
Maximum average launch power
Minimum average launch power
Maximum average power at
receiver
Receiver sensitivity
Dual-Port 10GBASE (MMSR or SMLR) Fiber Configurable Bypass NetMod
The dual-port 10GBASE (MMSR or SMLR) fiber configurable bypass NetMod
contains two fiber ports and link, activity, and bypass LEDs.
Link LED
Ports
Activity LED
Sourcefire 3D System Installation Guide
1000BASE-SX
LC duplex
1000Mbps
1250Mbps / 8b/10b encoding
Multimode
200 m (656 ft) for 62.5 μm/125 μm fiber
500 m (1640 ft) for 50 μm/125 μm fiber
770-860 nm (850 nm typical)
0 dBm
-9.5 dBm
0 dBm
-17 dBm
Bypass LED
Chapter 6
table to understand the
