Source fire Sourcefire 3D System Installation Manual page 154

Hardware Specifications
Sourcefire 7000 Series Devices
Version 5.2
The 3D7110 and 3D7120 System Components: Front View
features on the front of the appliance.
3D7110 and 3D7120 System Components: Front View
F D
EATURE
LCD panel Operates in multiple modes to configure the device,
display error messages, and view system status. For
more information, see
Device
Front panel USB Allows you to attach a keyboard to the device.
2.0 port
Front panel Houses LEDs that display the system's operating state, as
well as various controls, such as the power button. For
more information, see
page 154.
Sensing Contain the sensing interfaces that connect to the
interfaces network. For more information, see
Sensing Interfaces
3D7110 and 3D7120 Front Panel
A B
3D7110 and 3D7120 Front Panel Components
A USB 2.0 connector
B Reset button
C NIC2 activity LED
D System status LED
Sourcefire 3D System Installation Guide
ESCRIPTION
Using the LCD Panel on a Series 3
on page 111.
3D7110 and 3D7120 Front Panel
on page 157.
C D
E F G H
E NIC1 activity LED
F Hard drive activity LED
G ID button
H Power button and LED
Chapter 6
table describes the
on
3D7110 and 3D7120
154
