Hardware Specifications
Sourcefire 7000 Series Devices
3D7110 and 3D7120 Physical and Environmental Parameters (Continued)
P
ARAMETER
Cooling
requirements
Acoustic noise
Operating shock
Airflow

Sourcefire 3D7115 and 3D7125

LCD Panel
Version 5.2
D
ESCRIPTION
900 BTU/hour
You must provide sufficient cooling to maintain the appliance within its
required operating temperature range. Failure to do this may cause a
malfunction or damage to the appliance.
64 dBA at full processor load, normal fan operation
Meets GR-63-CORE 4.6 Acoustic Noise
Complies with Bellecore GR-63-CORE standards
3 3
140 ft (3.9 m ) per minute
Airflow through the appliance enters at the front and exits at the rear with no
side ventilation.
The 3D7115 and 3D7125 devices, part of the 71xx Family, are delivered with
four-port copper interfaces with configurable bypass capability, and eight
hot-swappable small form-factor pluggable (SFP) ports without bypass capability.
To ensure compatibility, use only Sourcefire SFP transceivers. See
Series 3 Information on page 232 for safety considerations for 71xx Family
appliances.
See the following sections for more information:
• 3D7115 and 3D7125 Chassis Front View
• 3D7115 and 3D7125 Chassis Rear View
• 3D7115 and 3D7125 Physical and Environmental Parameters
3D7115 and 3D7125 Chassis Front View
The front of the chassis contains the LCD panel, USB port, front panel, copper
sensing interfaces, and SFP sockets.
3D7115 and 3D7125 (Chassis: GERY-1U-8-4C8S-AC) Front View
USB 2.0 Port Front Panel
Sourcefire 3D System Installation Guide
on page 162
on page 168
Copper Sensing Interfaces
Chapter 6
Sourcefire
on page 170
SFP Sockets
