CAUTION!
PLEASE KEEP POWER
SWITCH ON BEFORE
OPERATING THIS EQUIPMENT
Turbo Air Speed up the Pace of Innovation
Undercounter Freezer
Service Manual
Please read this manual completely before attempting to install or operate this equipment!
Undercounter Freezer
TUF-36SD
www.turboairinc.com
Advertisement
Related Manuals for Turbo Air TUF-36SD
Summary of Contents for Turbo Air TUF-36SD
- Page 1 CAUTION! PLEASE KEEP POWER SWITCH ON BEFORE OPERATING THIS EQUIPMENT Turbo Air Speed up the Pace of Innovation Undercounter Freezer Service Manual Please read this manual completely before attempting to install or operate this equipment! Undercounter Freezer TUF-36SD www.turboairinc.com...
- Page 2 MUF-36/TUF-36SD 1. MUF-36/TUF-36SD Explode View Part Cord Part Name Part Cord Part Name WM35800100 SHELF(MUF) UF36570701 EVAP FAN DUCT(TUF) M367800101 SHELF(TUF) WF33570700 EVAP FAN DUCT(MUF) M369500200 CABINET ASSY M725300201 SHELF STARDAND IS 4420DWSG-1 CONDENSER FAN MOTOR M722900209 TOP HINGE L...
- Page 3 2. Wiring Diagram (TUF-36SD) Wiring Diagram (MUF-36)
-
Page 4: Main Components
3. MAIN COMPONENTS 3-1.COMPRESSOR MODEL PART NAME PART NO. TYPE OF INPUT REFRIGERANT 115V,60Hz MUF-36 SK1A1C-L2W RSCR R-134a 115V,60Hz TUF-36SD SK1A1C-L2W RSCR R-134a 3-2.CONDENSER FAN MOTOR MODEL PART NAME PART NO. POLE INPUT TYPE BLADE MAKER SHADED MUF-36 115V,60Hz POLE... -
Page 5: Service Part List
5-1. Service Part List UF-36 Remark Part Name Part Code Description MUF- TUF- 36SD COUNTER TOP ASSY WU36700100 COUNTER TOP ASSY UF36570200 DOOR ASSY(L) M361700201 DOOR ASSY(R) M361700101 DOOR ASSY(L) WM36700201 DOOR ASSY(R) WM36700101 DOOR GASKET M362300104 DOOR BUSHING M729200100 DOOR BUSHING M720700107 SPRING BAR... - Page 6 5-2. Capillary Tube Spec Suction Pipe A Suction Pipe B Model Tube I.D Length F Tube I.D Length F TUF-36SD 2.4X 1.2 617mm 2.4X 1.2 3383 mm MUF-36 2.4X 1.2 617mm 2.4X 1.2 3383 mm 5-3. The cycle pressure of model starting (refrigerant weight)
