Summary of Contents for Beltone EazyTrim Plus EZTP73-V BTE
- Page 1 Technical Manual Beltone EazyTrim Plus BTE EZTP73-V BTE Global Technical Operations gto.gnresound.com Lautrupbjerg 9 • DK-2750 Ballerup • Denmark E-Mail: Service@Beltone.com...
-
Page 2: Table Of Contents
Doc. No. 0121820 rev. B Table of contents Description...........................3 Part list..........................4 Dis-assembly HI ........................5 Microphone & Receiver ....................6-7 Mounting PB Battery Springs & Telecoil ................8 Page 2 of 8... -
Page 3: Description
The Beltone EZ TRIM PLUS offers the benefits of modern digital technology with the ease of conventional fitting. The Beltone EZ TRIM PLUS is an easy adjustable BTE with digital signal processing that does not require computer or fitting software. Fitting is done by using the four digital trimmers, allowing you to do a personal and easy fit: •... -
Page 4: Part List
Part List Doc. No. 0121820 rev. B Item Part No. Item Part No. AMP (COMPL IN FRAME) 16015100 REC COMPL MOUNT W/WIRES,SUSP 613-004-001-33 T-COIL-HOLDER INTEGRA 513-010-100-01 REC SUSPENSION INTEGRA 550-003-000-00 T-COIL Y21 INTEGRA,S-VDD/ NANO 576-002-080-00 WIRE,ESW,RED,7X32U,23MM 15129623 PB SWITCH 611-000-010-00 WIRE,ESW,AMBER7X32U,23MM 15129723 BATT. -
Page 5: Dis-Assembly Hi
Dis-assembly HI Doc. No. 0121820 rev. B Front cap Slot Insert a screwdriver in the Pull out the ear hook Gently remove the front cap slot to release the front cap Gently separate the housing parts from frame as shown. Tip: Open the batt. -
Page 6: Microphone & Receiver
Microphone & Receiver Doc. No. 0121820 rev. B The mic is covered in the The rec is covered with a The rec is covered indicated area by standard nail second layer to protect the with standard nail varnish to protect the mic and soldering pads and to keep the varnish to protect the to keep the wires in place... -
Page 7: Microphone & Receiver
Microphone & Receiver Doc. No. 0121820 rev. B Pull back till suspensions Gabs flush with dotted line Connect and place the rec wires as shown Add grease/Molycote onto the edge of both sides of the re- Add grease/Molycote on both housing parts ceiver compartment Page 7 of 8... -
Page 8: Mounting Pb Battery Springs & Telecoil
Replacing PB Battery Springs & Telecoil Doc. No. 0121820 rev. B Amplifier is shown from both sides Batt spring (+) Batt spring (-) Unsolder the battery Soldering points for the two PB terminals springs from the PCB To release the contacts from the BTE frame, push the encircled area and lift out the spring/...
