- Page 1 Technical Manual Beltone Paris Platform BTE Global Technical Operations gto.gnresound.com Lautrupbjerg 7 • DK-2750 Ballerup • Denmark E-Mail: Service@Beltone.com...
-
Page 2: Table Of Contents
Doc 0176160 rev. I Table of Contents Form-Factor-Matrix ......................3 Colour Overview ........................4 Part List ......................... 5-10 Disassemble Procedure ....................11 Replacing Toggle Cap .......................12 Replacing Top HSG, Module, PB & Mic Cover ..............13 Replacing Bottom HSG with ID Plate ................14 Service & Postponement Procedure .................15 Connecting the Programming Adaptor ................16 Programming Adaptor Clip ....................17 Test Equipment ........................18... -
Page 3: Form-Factor-Matrix
This Technical Manual serves to outline the service & postponement procedure for products listed in the form-factor-matrix below: Platform Product Name Model Data Sheet REACH 66 RCH66D 16649700 Paris 60 BTE IDENTITY 66 IDT66D 16765400 REACH 76 RCH76D 16649800 Paris 70 BTE... -
Page 4: Colour Overview
Colour Overview Doc 0176160 rev. I RUBY PRECIOUS MAJESTIC PRECIOUS DOVE BLUE CHROME ROSE PINK BRONZE WHITE SILVER BLACK BEIGE LIGHT GREY GREY BROWN CHARCOAL STONE SOFT BEIGE SOFT GREY SOFT STONE Page 4 of 19 Not subject to issue control when printed... -
Page 5: Part List
Part List Doc 0176160 rev. I Description PARIS 60 PARIS 70 PARIS 80 CHILDLOCK, BLUE 16165801 15966401 15966401 CHILDLOCK, RED 16165800 15966400 15966400 THIN TUBE ADAPT 16187000 16187000 PIN Ø0.6 (Front) 15344200 16059700 16059600 PIN Ø0.6 (Rear) 16059800 15168000 16342400 PIN Ø0.6 (Bat door) 16059700 16059700... - Page 6 Part List Doc 0176160 rev. I Service Modules (ASM FRAME, PROGRAMMED): PARIS 60 PARIS 70 PARIS 80 RCH66D 16911600 RCH76D 16911800 RCH86D 16962000 IDT66D 16911700 IDT76D 16911900 IDT86D 16962100 TBR76 16912000 Service modules are none serviceable at local site. Instead defective service modules must be returned to Global Repair Site Description Part No PROG.
- Page 7 Part List - Housing Parts Doc 0176160 rev. I HI Colour PARIS 60/70/80 PARIS 60/70/80 PARIS 70/80 PARIS 70/80 PARIS 60 PARIS 70/80 Description Mic Cover Actuator PB Toggle VC VC Cover Batt Door Batt Door BEIGE 16186100 16960100 16187500 16381900 16386400 16387400...
- Page 8 Part List - Housing Parts Doc 0176160 rev. I HI Colour PARIS 60 PARIS 70 PARIS 80 PARIS 60 PARIS 70 PARIS 80 Description HSG Bottom HSG Bottom HSG Bottom HSG Top HSG Top HSG Top BEIGE 16184400 16184500 16184600 16187700 16187200 16187900...
- Page 9 16400013N 16400113N RUBY RED 16400014N 16400114N ROSE PINK 16400015N 16400115N CHROME 16400016N 16400116N Mounting the Replacement Kits: Please refer to Doc 0173460: WORKING INSTRUCTIONS,REPLACEMENT KITS, BELTONE PARIS BTE PLATFORM Page 9 of 19 Not subject to issue control when printed...
- Page 10 Part List - Thin Tubes & Domes Doc 0176160 rev. I THIN TUBE BLISTER PACKS THIN TUBE DOMES Part No (5 tubes & 3 cleaning wires) Blister Pack Description THIN TUBE 2,0A,R,BLSTR 18628600 (10 pcs) (8 pcs) THIN TUBE 2,0B,R,BLSTR 18628700 DOME,THNTUB/REC,SZ5,SM 18500800...
-
Page 11: Disassemble Procedure
Disassemble Procedure Doc 0176160 rev. I Pin removal tool packed Short pin Long pin w/user instructions p/n 15502500 Batt pin Remove the hook by turning Remove the 3 pins from Remove battery door Remove the bottom HSG it counter clockwise HSG using pin removal tool PARIS 60 PARIS 70/80 (70 is shown) -
Page 12: Replacing Toggle Cap
Replacing VC Toggle Doc 0176160 rev. I Toggle remover Place the widest gap on the tool on the top of the toggle switch cap. Slowly slide the tool as shown until the cap is trapped. Then continue sliding the tool until the cap is off Mount the new toggle switch cap by inserting Press the top part of the cap into the device to the lower part of the cap as shown... -
Page 13: Replacing Top Hsg, Module, Pb & Mic Cover
Replacing Top HSG, Module, PB & Mic Cover Doc 0176160 rev. I Separate the module from the top housing. Note that the PB Gently push out PB cover from top HSG (from outside). When mounting the new cover is not glued to the top HSG PB cover, make sure bottom part of PB cover is placed properly Top HSG with hole to Push out mic cover from... -
Page 14: Replacing Bottom Hsg With Id Plate
Replacing Bottom HSG with ID Plate Doc 0176160 rev. I 0812345678 RCH76D Two prong One prong ID plate Place ID plate in the new bottom HSG. Insert the side with two prong first and then one prong side Note that ID plate is NOT an available pare part Old Bottom Housing New Bottom Housing... -
Page 15: Service & Postponement Procedure
- Transfer ID-plate from old housing to new housing - Verify battery door by open and close once For detailed process refer to Doc 0173460: WORKING INSTRUCTIONS,REPLACEMENT KITS, BELTONE PARIS BTE PLATFORM Page 15 of 19 Not subject to issue control when printed... -
Page 16: Connecting The Programming Adaptor
Connecting the Programming Adaptor Doc 0176160 rev. I Click Insert the one end of the prog adaptor into Push the bottom part of the prog adapt until it clicks to lock it on the device the square programming port of the device Push the button to unlock the prog adaptor from the battery door Gently peel off the prog adapt from the HI Page 16 of 19... -
Page 17: Programming Adaptor Clip
Programming Adaptor Clip Doc 0176160 rev. I Clip for prog adaptor L/R It is important to have the programming cable connected before adding the clip to the programming adaptor. Add the clip as shown in the pics. The clip is recommended to be used during test / fitting in order to keep the prog cable connected during the complete procedure To remove the clip firmly grip this side of prog adapt Pull tip of the clip... -
Page 18: Test Equipment
Test Equipment Doc 0176160 rev. I CS44 Prog cable Prog adaptor clip Prog adaptor Instrument fixture (Left blue is shown) 17736900 Red p/n 18041400 p/n 16695100 9022 907 69019 (R) 17736901 Blue (incl red & blue clip) for final HI test 9022 907 69029 (L) 2cc coupler 2cc coupler insert BTE... -
Page 19: Testing
Testing Doc 0176160 rev. I Use of the test fixture is mandatory for all Paris Platform BTE during AUDIOmaster testing. To use the fixture, place the instrument under test in the fixture according to picture. Connect the programming cable to the programming adaptor and then attach the programming adaptor to the device. Select test program in AUDIOmaster and press ‘Start’...
