OPERATOR'S MANUAL
1/2 in., 19.2 VOLT CORdLESS dRILL-dRIVER
VARIABLE SPEEd/REVERSIBLE
Model No.
315.115810
WARNING:
To reduce the risk of injury,
the user must read and understand the
operator's manual before using this
product.
Customer Help Line: 1-800-932-3188
Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA
Visit the Craftsman web page: www.sears.com/craftsman
983000-880
2-26-08 (REV:02)
Save this manual for future reference
BATTERIES ANd CHARGERS
SOLd SEPARATELY
R

Advertisement

Table of Contents
loading

Summary of Contents for Craftsman 315.115810

  • Page 1 Customer Help Line: 1-800-932-3188 Sears, Roebuck and Co., 3333 Beverly Rd., Hoffman Estates, IL 60179 USA Visit the Craftsman web page: www.sears.com/craftsman 983000-880 Save this manual for future reference 2-26-08 (REV:02)
  • Page 2: Table Of Contents

    If this Craftsman tool fails to give complete satisfaction within one year from date of purchase, RETURN IT TO ANY SEARS STORE OR OTHER CRAFTSMAN OUTLET IN THE UNITEd STATES FOR FREE REPLACEMENT. If this Craftsman tool is used for commercial or rental purposes, this warranty applies for only 90 days from the date of purchase.
  • Page 3: General Safety Rules

    BATTERY PACK 315. 259260 Power tools are dangerous in the hands of untrained us- (Ni-Cd) (140351001) ers. 315.115810 1425301 ( 11041)  Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts, and any 130279003, 315.115730 other condition that may affect the power tool’s...
  • Page 4: Specific Safety Rules

    GENERAL SAFETY RULES  Use the power tool, accessories and tool bits etc., Shorting the battery terminals together may cause in accordance with these instructions and in the burns or a fire. manner intended for the particular type of power  Under abusive conditions, liquid may be ejected tool, taking into account the working conditions from the battery, avoid contact.
  • Page 5: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper inter- pretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME dESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz...
  • Page 6: Symbols

    If you do not understand the warnings and to your nearest SEARS PARTS ANd REPAIR SERVICE instructions in the operator’s manual, do not use this CENTER for repair. When servicing, use only identical product. Call the Craftsman Consumer Helpline at replacement parts. 1-800-932-3188 for assistance. WARNING The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.
  • Page 7: Features

    FEATURES PROdUCT SPECIFICATIONS No Load Speed ....... 0-400/0-1,400 r/min. (RPM) Chuck ............1/2 in. Keyless Clutch ..............24 Position Motor ............... 19.2 Volt DC Torque ..............420 in.lb. Switch ............Variable Speed Gear Train ...............2 Speed REAR VIEW TWO-SPEED GEAR TRAIN (HI-LO) LEVEL TORQUE ADJUSTMENT RING...
  • Page 8: Assembly

    FEATURES KNOW YOUR dRILL-dRIVER KEYLESS CHUCK See Figure 1. The keyless chuck allows you to hand-tighten or release The safe use of this product requires an understanding of the drill bit in the chuck jaws. the information on the tool and in this operator’s manual LEd WORKLIGHT as well as a knowledge of the project you are attempting.
  • Page 9: Operation

    This product will accept DieHard 19.2 V lithium-ion bat- ® See Figure 2. tery packs and Craftsman 19.2 V nickel-cadmium battery packs.  Lock switch trigger on the drill by placing the direction For complete charging instructions, refer to the Operator’s of rotation selector in center position.
  • Page 10 OPERATION To stop the drill, release the switch trigger and allow the WARNING: Battery tools are always in operating chuck to come to a complete stop. condition. Therefore, switch should always be locked NOTE: The drill will not run unless the direction of rotation when not in use or carrying at your side.
  • Page 11 OPERATION KEYLESS CHUCK TO DECREASE TORQUE See Figure 5. ADJUSTING RING The drill has a keyless chuck to tighten or release drill bits in the chuck jaws. The arrows on the chuck indicate which direction to rotate the chuck body in order to LOCK (tighten) or UNLOCK (release) the drill bit.
  • Page 12 OPERATION BIT STORAGE CHUCK UNLOCK COLLAR See Figure 8. DRILL BIT (RELEASE) When not in use, bits provided with the drill can be placed in the storage area located on the base of the drill. SCREWDRIVER BIT CHUCK JAWS LOCK CHUCK (TIGHTEN) BODY...
  • Page 13: Operation

    OPERATION LEVEL AdJUSTING THE AUXILIARY HANdLE ASSEMBLY See Figure 11.  Loosen the auxiliary handle assembly by turning the knob counterclockwise.  Rotate the auxiliary handle assembly to the desired location.  Tighten the auxiliary handle assembly securely by turn- ing the knob clockwise.
  • Page 14: Maintenance

    WARNING: When servicing, use only identical Avoid using solvents when cleaning plastic parts. Most Craftsman replacement parts. Use of any other part plastics are susceptible to damage from various types of may create a hazard or cause product damage. commercial solvents and may be damaged by their use.
  • Page 15: Maintenance

    MAINTENANCE BATTERY PACK REMOVAL ANd PREPARATION  Open the chuck jaws and remove the hex key. Using a FOR RECYCLING screwdriver, remove the chuck screw by turning it in a clockwise direction. To preserve natural resources, please recycle or dispose of batteries NOTE: The chuck screw has left hand threads.
  • Page 16: Exploded View And Parts List

    CRAFTSMAN 19.2 VOLT CORdLESS dRILL-dRIVER MOdEL NO. 315.115810 The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your CORdLESS dRILL-dRIVER or when ordering repair parts. SEE BACK PAGE FOR PARTS ORdERING INSTRUCTIONS...
