Summary of Contents for Longevity MigWeld 200S
- Page 1 Operating Manual MigWeld 200S 200 AMP Inverter MIG/STICK Welder 220v - 1 -...
- Page 2 PG. 7-9: Warning and Safety Information PG. 10: General Description PG. 11: Specifications and Ratings PG. 12-13: Operations and Controls PG. 14-15: Set-Up for Different Processes PG. 16: Operating the MigWeld 200S PG. 17: Enjoy your new welding machine from LONGEVITY! - 2 -...
- Page 3 THANK YOU! We, at LONGEVITY, want to thank you for purchasing our product. You are almost ready to experience Longevity Welding first hand. Longevity definitely appreciates your business and understand that this equipment may be overwhelming to setup and operate so we have prepared a manual that will assist you in understand your new plasma cutter/welder.
- Page 4 Complaints: complaints@longevity-inc.com Please join our welding forums to share welding tips and tricks, to receive useful information from customers who also use our products, and to be a part of the Longevity™ welding community at www.freeweldingforum.com Check out LONGEVITY Racing at www.longevity-racing.com...
- Page 5 LONGEVITY customers with repairs, replacement, and service. If your unit is not manufactured by Longevity and you cannot receive service from your manufacturer or seller, Longevity will lend out hand. Our warranty policy is also available for all plasma cutters and welders.
-
Page 6: Warnings And Safety
Warnings and Safety Welding and plasma cutting may be dangerous to the operator and to bystanders, if the equipment is not operated properly. Welding or cutting must be performed in accordance with all relevant safety regulations. Carefully read and understand this instruction manual before installing and operating this equipment. - Page 7 Welding splash is a fire hazard. Keep flammable material away from the work place. Keep a fire extinguisher nearby, and have all personnel trained in its use. Surface noise generated while welding or cutting can be harmful to hearing. In the event of a machine fault. Refer to this instruction manual.
-
Page 8: Safety Tips
The arc spray and metal spray from machine use may cause nearby fires. Use caution. If, after reviewing this manual, you have any problems in setting up or operating your machine, contact us at help@longevity-inc.com. - 8 -... - Page 9 WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood, by the operator, that common sense and caution are factors, which cannot be built into this product, but must be supplied by the operator.
- Page 10 reduce the possibility of electric shock. The MigWeld140 power switch is to be in the OFF (“O”) position when installing work cable and gun and when connecting power cord to input power. Always wear dry, protective clothing and welding gloves and insulated footwear. Always operate the welder in a clean, dry, well-ventilated area.
- Page 11 welding may have other health effects, which are not known. Model MIGWELD200S Rated Input Voltage 220V/1Phase Frequency (Hz) 50/60 No-Load Loss Efficiency 0.80 Power Factor 0.73 No-load output voltage 50-80V Rated Input Current 37.4A Output Voltage 15.5-24V adjustment Range Output Current Range 30-200A Load Duty Cycle 60%@200A/24V...
-
Page 12: Operation And Controls
Allows easy selection of the welding process desired. 3. Wire Feed/ Spool Gun Knob Easily switches between the wire feed and spool gun functions of the MigWeld 200S 4. Voltage/ Arc Force Knob When the unit is in MIG mode, this knob adjusts the welding voltage. If the unit is in STICK mode, the knob adjusts the amount of arc force. - Page 13 6. Reference table for welding conditions Thickn Diameter of Welding Applicable to OUR Welding Parent metal wire current welding machine's method (Φ) (mm) range (A) model Carbon steel, common low 0.8-8.0 CO2/MAG 0.8/1.0/1.0 60--230 MigWeld 200S alloy steel - 13 -...
- Page 14 Set-up for using MIG function: Power supply meter cylinder AC 220V 50/60Hz Back Earth clamp Work piece Mig torch Set-up for using Spool Gun Function: Power supply meter cylinder AC 220V 50/60Hz Back Earth clamp Work piece Pull mig torch - 14 -...
-
Page 15: Power Supply
Set-up for using Stick welding function: Power supply AC 220V 50/60Hz Back Earth clamp Work piece Electrode holder - 15 -... - Page 16 Operation 1. Turn the power switch to the “ON” setting, the LCD display will show set current volume and the cooling fan will beginning to revolve. 2. Adjust the Voltage/ Arc Force Knob and the Wire Speed / Stick Amps according to your needs. 3.
- Page 17 LONGEVITY® Global, Inc. thanks you for your purchase and the opportunity to be able to serve you. If, after reviewing this manual, you have any problems in setting up or operating your machine, contact us at help@longevity-inc.com. LONGEVITY® Global, Inc.
