Hypertherm MAX200 Instruction Manual page 3

Changed Page
Cover New Revision
Title Page New Revision
2.2 Revised duty cycle rating
2.3 Added 073036 power supply
4.18 & 19 Added 120667 electrode
4.21-39 Added 120667 electrode, revised motion delay and notes
5.3 Removed reference to machine torch options
5.5 Removed reference to machine torch options
5.9 Removed reference to machine torch options
5.11 Corrected 007022 shunt rating
5.13 Corrected item 9 P/N and description
5.14 & 15 Revised coolant pump and motor listing
5.18 - 21 Added 120667 electrode
5.22 & 23 General clairifcation
5.24 Added 120667 electrode
5.25 Revised figure 5- 12
5.26 Added 120667 electrode & revised figure 5-13
5.27- 32 Added MAX200 Rev 1 hand torch and leads
b.1 Spelling correction
d.2-4 Added 120667 electrode
Changed Page
Cover New Revision
Title Page New Revision
4.21 Correction, view of 020917 shield
4.27 Correction, view of 020917 shield
4.34 Correction, view of 020917 shield
5.14 Revised Figure 5-7, new sol. Valve SA 129383
5.15 New Solenoid valve subassembly
5.19 Revised Figure 5-8 to include 020917 shield
d.3 Revised Figure d-1 to include 020917 shield
Appendix B New Coolant MSDS
DIAGRAMS 013179, Added sheet 9
DIAGRAMS Add 029313 Coolant Diagram
Description
Description
2
IM087 Revision 13 1/99
IM87 Revision 12 8/98
